ASSEMBLY INSTRUCTIONS
10.
Attach rear beams (C1/C2) to posts
(A5/A6) using bolts (CC), flat washers
(BB) and spring washers (EE).
Tighten with wrench (Z2).
Hardware Used
CC M6 x 45 Bolt
BB
M6 Flat Washer
Spring Washer
EE
Z2
M6 Wrench
11-1. Attach beams (B3/B4) to posts (A3/A4)
using bolts (DD), flat washers (BB) and
spring washers (EE). Tighten with
wrench (Z2).
Hardware Used
DD
M6 x 20 Bolt
BB
M6 Flat Washer
Spring Washer
EE
Z2
M6 Wrench
11-2. Attach beams (B3/B4) to posts
(A3/A4) using bolts (HH). Tighten
with allen key (Z1).
Hardware Used
HH
M6 x 15 Sockets bolt
Z1
M6 Socket Head
Allen Key
x 8
x 8
x 8
x 1
x 4
x 4
x 4
x 1
x 4
x 1
11
