"Pipe Length on" means that the length of both pipes/components
has to be entered before every welding, "off," that this is not
possible.
"Weather Conditions on" means that the weather has to be
selected in a list before every welding, "off," that this is not
possible.
"Geo-data on" (only if GPS module) means that the geographic
coodinates have to be recorded after every welding (see Sect. 6.7
for details), "off," that this is not possible.
"Installing Company on" means that the company that performs
the installation work has to be entered before every welding,
"off," that this is not possible.
"Print Tags – M – " means that by pressing the MENU key, the
user can access a sub-menu for starting to print (a) label(s) with
reference to a given welding operation, with the optional label
tag printer.
All data can also be read from a bar code with the scanner, provided such a bar code
is available.
11

Self-Monitoring Functions Overview

11.1

Errors During Data Input

• Code Error
An erroneous input has occurred, a code tag is poor or has an error in code symbology or code
reading was improper.
• No Contact
There is no properly established electric contact between the welding unit and the fitting (check
push-on terminal on fitting), or the heater coil is defective.
• Low Voltage
The input voltage is below 175 volts. Adjust generator output voltage.
• Overvoltage
The input voltage is over 290 volts. Decrease generator output voltage.
• Overheated
The transformer temperature is too hot. Let the welding unit cool down for about 1 hour.
• System Error
CAUTION! The welding unit has to be disconnected immediately from both the
power supply and the fitting. The auto-test has detected an error in the system. The
unit must no longer be operated and has to be sent to an approved shop for check
and repair.
• Temperature Error
The ambient temperature measured is outside the operating range of the welding unit, i.e.,
below – 20°C (– 4°F) or over + 60°C (+ 140°F).
• Temperature Sensor Defective
The ambient temperature sensor on the welding cable is damaged or defective.
• Clock Error
The internal system clock works improperly or is defective. Reset it, or send the welding unit to
the manufacturer for check and service.
• Unit to Service
The recommended next service date for the welding unit is overdue. The service due message has
to be acknowledged by pressing the START/SET key. Send the welding unit to the manufacturer
or an approved service point for service and check-up.
ENGLISH
Data Recording
Pipe Length
>Weather Cond.
Geo-data
Display 27
Data Recording
>Geo-data
Installing Comp.on
Print Tags
Display 28
on
on
off
off
-M-
