Maintenance
Disassembly
•
Twist both of the inner tube ends until the tabs line up
with the keyways.
•
Pull the inner tube ends outward.
INNER TUBE
14
INNER TUBE
TAB
KEYWAY
F. Remove the Float Valve
•
Turn the splash shield counterclockwise one or two
turns.
CAP AND
FILTER SCREEN
FLOAT
•
Pull the float valve forward and off the mounting
bracket.
•
Disconnect the water inlet tube from the float valve at
the compression fitting.
•
Remove the cap and filter screen for cleaning.
Section 4
FLOAT VALVE
BRACKET
COMPRESSION
FITTING
SHUT-OFF VALVE
SPLASH SHIELD
Part Number 040001360 6/14
