Implémentation MIDI
3. Parameter Address Map
* Transmission of "#" marked address is divided to some packets. For example, ABH in
hexadecimal notation will be divided to 0AH and 0BH, and is sent/received in this
order.
1 RD-700SX (Model ID = 00H 00H 03H)
❍Indivisual Parameters
* These messages are transmitted when Bulk Dump Temporary funcion is executed.
* Please don't use a parameter or a address marked <Reserved>.
* The parameters for Setup are temporary. If you want to leave the parameters after the
RD-700SX is turned off , execute SETUP Write.
+------------------------------------------------------------------------------+
| Start
|
|
Address |
Description
|-------------+----------------------------------------------------------------|
| 01 00 00 00 | System
|-------------+----------------------------------------------------------------|
| 10 00 00 00 | SETUP (Temporary)
+------------------------------------------------------------------------------+
* System
+------------------------------------------------------------------------------+
| Start
|
|
Address |
Description
|-------------+----------------------------------------------------------------|
| 01 00 00 00 | System Common
| 01 00 02 00 | System Sound Control
| 01 00 03 00 | System Favorite SETUP
| 01 00 04 00 | System V-Link
| 01 00 05 00 | System One Touch Piano (TYPE A)
| 01 00 06 00 | System One Touch Piano (TYPE B)
| 01 00 07 00 | System One Touch EPiano (TYPE A)
| 01 00 08 00 | System One Touch EPiano (TYPE B)
+------------------------------------------------------------------------------+
* SETUP (Temporary)
+------------------------------------------------------------------------------+
| Start
|
|
Address |
Description
|-------------+----------------------------------------------------------------|
| 10 00 00 00 | SETUP Common
| 10 00 02 00 | SETUP Rhythm/Arpeggio
| 10 00 03 00 | SETUP MFX (MFX1)
| 10 00 05 00 | SETUP MFX (MFX2)
| 10 00 07 00 | SETUP Chorus
| 10 00 08 00 | SETUP Reverb
| 10 00 10 00 | SETUP Internal Zone (UPPER1)
| 10 00 11 00 | SETUP Internal Zone (UPPER2)
| 10 00 12 00 | SETUP Internal Zone (LOWER1)
| 10 00 13 00 | SETUP Internal Zone (LOWER2)
| 10 00 14 00 | SETUP External Zone (UPPER1)
| 10 00 15 00 | SETUP External Zone (UPPER2)
| 10 00 16 00 | SETUP External Zone (LOWER1)
| 10 00 17 00 | SETUP External Zone (LOWER2)
| 10 00 20 00 | SETUP Part (Part: 01)
| 10 00 21 00 | SETUP Part (Part: 02)
|
:
|
:
| 10 00 2F 00 | SETUP Part (Part: 16)
|-------------+----------------------------------------------------------------|
| 10 00 30 00 | SETUP TW-Organ
1 Backup
| 10 00 31 00 | SETUP TW-Organ
2 Backup
|
:
|
:
| 10 00 39 00 | SETUP TW-Organ 10 Backup
+------------------------------------------------------------------------------+
* System Common
+------------------------------------------------------------------------------+
|
Address
|
Description
|-------------+----------------------------------------------------------------|
|#01 00 00 00 | 0000 aaaa |
|
| 0000 bbbb |
|
| 0000 cccc |
|
| 0000 dddd | Master Tune
|
|
|
|-------------+-----------+----------------------------------------------------|
| 01 00 00 04 | 000a aaaa | SETUP Control Channel
|
|
|
|-------------+-----------+----------------------------------------------------|
| 01 00 00 05 | 0000 000a | Clock Source
|
|
|
| 01 00 00 06 | 0000 000a | Clock Out
|
|
|
|-------------+-----------+----------------------------------------------------|
| 01 00 00 07 | 0000 000a | Damper Polarity
|
|
|
| 01 00 00 08 | 0000 000a | FC1 Polarity
|
|
|
| 01 00 00 09 | 0000 000a | FC2 Polarity
|
|
|
|-------------+-----------+----------------------------------------------------|
| 01 00 00 0A | 0000 000a | EQ Mode
|
|
|
|-------------+-----------+----------------------------------------------------|
| 01 00 00 0B | 0000 000a | Pedal Mode
|
|
|
|-------------+-----------+----------------------------------------------------|
| 01 00 00 0C | 0aaa aaaa | System FC1 Assign
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 01 00 00 0D | 0aaa aaaa | System FC2 Assign
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|-------------+-----------+----------------------------------------------------|
| 01 00 00 0E | 0000 000a | Tone Remain
|
|
|
|-------------+----------------------------------------------------------------|
| 00 00 00 0F | Total Size
+------------------------------------------------------------------------------+
164
(24 - 2024) |
-100.0 - 100.0 [cent]
(0 - 16) |
1 - 16, OFF
(0 - 1) |
INT, MIDI
(0 - 1) |
OFF, ON
(0 - 1) |
STANDARD, REVERSE
(0 - 1) |
STANDARD, REVERSE
(0 - 1) |
STANDARD, REVERSE
(0 - 1) |
SETUP, SYSTEM
(0 - 1) |
SETUP, SYSTEM
(0 - 108) |
OFF, CC01 - CC31, CC33 - CC95, |
BEND-UP, BEND-DOWN, AFTERTOUCH, |
OCT-UP, OCT-DOWN, START/STOP, |
TAP-TEMPO, RHY PLY/STP, ARPEGGIO SW, |
MFX ON/OFF, MFX CONTROL, SNG PLY/STP, |
SETUP-UP, SETUP-DOWN
(0 - 108) |
OFF, CC01 - CC31, CC33 - CC95, |
BEND-UP, BEND-DOWN, AFTERTOUCH, |
OCT-UP, OCT-DOWN, START/STOP, |
TAP-TEMPO, RHY PLY/STP, ARPEGGIO SW, |
MFX ON/OFF, MFX CONTROL, SNG PLY/STP, |
SETUP-UP, SETUP-DOWN
(0 - 1) |
OFF, ON
* System Sound Control
+------------------------------------------------------------------------------+
|
Address
|
|-------------+----------------------------------------------------------------|
| 01 00 02 00 | 0aaa aaaa | Low band Attack time
| 01 00 02 01 | 0aaa aaaa | Low band Release time
| 01 00 02 02 | 00aa aaaa | Low band Threshold
|
|
|
|
|
|
|
|
| 01 00 02 03 | 0000 aaaa | Low band Ratio
|
|
|
|
|
|
| 01 00 02 04 | 000a aaaa | Low band Level
|
|
|
|
|
|
| 01 00 02 05 | 0aaa aaaa | Mid band Attack time
| 01 00 02 06 | 0aaa aaaa | Mid band Release time
| 01 00 02 07 | 00aa aaaa | Mid band Threshold
|
|
|
|
|
|
|
|
| 01 00 02 08 | 0000 aaaa | Mid band Ratio
|
|
|
|
|
|
|
|
| 01 00 02 09 | 000a aaaa | Mid band Level
|
|
|
|
|
|
|
|
| 01 00 02 0A | 0aaa aaaa | High band Attack time
| 01 00 02 0B | 0aaa aaaa | High band Release time
| 01 00 02 0C | 00aa aaaa | High band Threshold
|
|
|
|
|
|
|
|
|
|
| 01 00 02 0D | 0000 aaaa | High band Ratio
|
|
|
|
|
|
|
|
|
|
|
| 01 00 02 0E | 000a aaaa | High band Level
|
|
|
|
|
|
|
|
|
| 01 00 02 0F | 0000 0aaa | Split Freq Low
|
|
|
|
| 01 00 02 10 | 0000 0aaa | Split Freq High
|
|
|
|
|
|
|-------------+----------------------------------------------------------------|
| 00 00 00 11 | Total Size
|
+------------------------------------------------------------------------------+
|
|
* System Favorite SETUP
|
+------------------------------------------------------------------------------+
|
|
Address
|
|
|-------------+----------------------------------------------------------------|
|
| 01 00 03 00 | 0aaa aaaa | Favorite SETUP 0 (Bank A)
|
| 01 00 03 01 | 0aaa aaaa | Favorite SETUP 1 (Bank A)
|
| 01 00 03 02 | 0aaa aaaa | Favorite SETUP 2 (Bank A)
|
| 01 00 03 03 | 0aaa aaaa | Favorite SETUP 3 (Bank A)
|
| 01 00 03 04 | 0aaa aaaa | Favorite SETUP 4 (Bank A)
|
| 01 00 03 05 | 0aaa aaaa | Favorite SETUP 5 (Bank A)
|
| 01 00 03 06 | 0aaa aaaa | Favorite SETUP 6 (Bank A)
|
|
| 01 00 03 07 | 0aaa aaaa | Favorite SETUP 7 (Bank A)
| 01 00 03 08 | 0aaa aaaa | Favorite SETUP 8 (Bank A)
|
| 01 00 03 09 | 0aaa aaaa | Favorite SETUP 9 (Bank A)
|
|
|
|
| 01 00 03 0A | 0aaa aaaa | Favorite SETUP 0 (Bank B)
| 01 00 03 0B | 0aaa aaaa | Favorite SETUP 1 (Bank B)
|
|
| 01 00 03 0C | 0aaa aaaa | Favorite SETUP 2 (Bank B)
| 01 00 03 0D | 0aaa aaaa | Favorite SETUP 3 (Bank B)
|
| 01 00 03 0E | 0aaa aaaa | Favorite SETUP 4 (Bank B)
|
| 01 00 03 0F | 0aaa aaaa | Favorite SETUP 5 (Bank B)
| 01 00 03 10 | 0aaa aaaa | Favorite SETUP 6 (Bank B)
| 01 00 03 11 | 0aaa aaaa | Favorite SETUP 7 (Bank B)
| 01 00 03 12 | 0aaa aaaa | Favorite SETUP 8 (Bank B)
| 01 00 03 13 | 0aaa aaaa | Favorite SETUP 9 (Bank B)
|
|
|
| 01 00 03 14 | 0aaa aaaa | Favorite SETUP 0 (Bank C)
|
| 01 00 03 15 | 0aaa aaaa | Favorite SETUP 1 (Bank C)
|
| 01 00 03 16 | 0aaa aaaa | Favorite SETUP 2 (Bank C)
|
| 01 00 03 17 | 0aaa aaaa | Favorite SETUP 3 (Bank C)
| 01 00 03 18 | 0aaa aaaa | Favorite SETUP 4 (Bank C)
|
| 01 00 03 19 | 0aaa aaaa | Favorite SETUP 5 (Bank C)
| 01 00 03 1A | 0aaa aaaa | Favorite SETUP 6 (Bank C)
| 01 00 03 1B | 0aaa aaaa | Favorite SETUP 7 (Bank C)
|
| 01 00 03 1C | 0aaa aaaa | Favorite SETUP 8 (Bank C)
| 01 00 03 1D | 0aaa aaaa | Favorite SETUP 9 (Bank C)
|
|
|
| 01 00 03 1E | 0aaa aaaa | Favorite SETUP 0 (Bank D)
| 01 00 03 1F | 0aaa aaaa | Favorite SETUP 1 (Bank D)
|
| 01 00 03 20 | 0aaa aaaa | Favorite SETUP 2 (Bank D)
| 01 00 03 21 | 0aaa aaaa | Favorite SETUP 3 (Bank D)
| 01 00 03 22 | 0aaa aaaa | Favorite SETUP 4 (Bank D)
|
| 01 00 03 23 | 0aaa aaaa | Favorite SETUP 5 (Bank D)
| 01 00 03 24 | 0aaa aaaa | Favorite SETUP 6 (Bank D)
|
| 01 00 03 25 | 0aaa aaaa | Favorite SETUP 7 (Bank D)
|
| 01 00 03 26 | 0aaa aaaa | Favorite SETUP 8 (Bank D)
| 01 00 03 27 | 0aaa aaaa | Favorite SETUP 9 (Bank D)
|-------------+----------------------------------------------------------------|
|
| 00 00 00 28 | Total Size
+------------------------------------------------------------------------------+
|
* System V-Link
+------------------------------------------------------------------------------+
|
Address
|
|-------------+----------------------------------------------------------------|
| 01 00 04 00 | 0000 000a | Switch
|
|
| 01 00 04 01 | 0000 000a | Mode
|
|
| 01 00 04 02 | 0aaa aaaa | Lowest No
|
| 01 00 04 03 | 0000 aaaa | Transmit Channel
| 01 00 04 04 | 0000 00aa | Transmit Port
|
|
| 01 00 04 05 | 0aaa aaaa | Key Range Lower
| 01 00 04 06 | 0aaa aaaa | Key Range Upper
| 01 00 04 07 | 0000 000a | Local Control
|
|
|
|-------------+----------------------------------------------------------------|
| 00 00 00 08 | Total Size
+------------------------------------------------------------------------------+
|
|
Description
|
-36, -35, -34, -33, -32, -31, -30, -29, -28, |
|
-27, -26, -25, -24, -23, -22, -21, -20, -19, |
|
-18, -17, -16, -15, -14, -13, -12, -11, -10, |
|
-9, -8, -7, -6, -5, -4, -3, -2, -1, 0 [dB]
|
1:1.0, 1:1.1, 1:1.2, 1:1.4, 1:1.6, |
|
1:1.8, 1:2.0, 1:2.5, 1:3.2, 1:4.0, |
|
1:5.6, 1:8.0, 1:16, 1:INF
|
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, |
|
10,11,12,13,14,15,16,17,18,19, |
|
20,21,22,23,24 [dB]
|
-36, -35, -34, -33, -32, -31, -30, -29, -28, |
|
-27, -26, -25, -24, -23, -22, -21, -20, -19, |
|
-18, -17, -16, -15, -14, -13, -12, -11, -10, |
|
-9, -8, -7, -6, -5, -4, -3, -2, -1, 0 [dB]
|
1:1.0, 1:1.1, 1:1.2, 1:1.4, 1:1.6, |
|
1:1.8, 1:2.0, 1:2.5, 1:3.2, 1:4.0, |
|
1:5.6, 1:8.0, 1:16, 1:INF
|
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, |
|
10,11,12,13,14,15,16,17,18,19, |
|
20,21,22,23,24 [dB]
|
-36, -35, -34, -33, -32, -31, -30, -29, -28, |
|
-27, -26, -25, -24, -23, -22, -21, -20, -19, |
|
-18, -17, -16, -15, -14, -13, -12, -11, -10, |
|
-9, -8, -7, -6, -5, -4, -3, -2, -1, 0 [dB]
|
1:1.0, 1:1.1, 1:1.2, 1:1.4, 1:1.6, |
|
1:1.8, 1:2.0, 1:2.5, 1:3.2, 1:4.0, |
|
1:5.6, 1:8.0, 1:16, 1:INF
|
0, 1, 2, 3, 4, 5, 6, 7, 8, 9, |
|
10,11,12,13,14,15,16,17,18,19, |
|
20,21,22,23,24 [dB]
|
200, 250, 315, 400, 500, |
|
|
2000, 2500, 3150, 4000, 5000, |
|
Description
|
|
|
Description
|
|
|
All,Out1,Out2,USB
|
|
(0 - 100) |
(0 - 100) |
(0 - 36) |
|
(0 - 13) |
|
(0 - 24) |
|
(0 - 100) |
(0 - 100) |
(0 - 36) |
|
(0 - 13) |
|
(0 - 24) |
|
(0 - 100) |
(0 - 100) |
(0 - 36) |
|
(0 - 13) |
|
(0 - 24) |
|
(0 - 6) |
630, 800 [Hz]
|
(0 - 6) |
6300, 8000 [Hz]
|
|
|
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
|
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
|
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
|
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
(0 - 100) |
|
|
(0 - 1) |
OFF,ON
|
(0 - 1) |
BANK/PC.NOTE
|
(0 - 127) |
(0 - 15) |
(0 - 3) |
|
(0 - 87) |
(0 - 87) |
(0 - 1) |
OFF, ON
|
|
