Cleaning After Use; Maintenance And Inspection; Changing The Internal Deburrer Blade - Rothenberger ROPOWER 50 R Mode D'emploi

5.10

Cleaning after use

Do not remove metal and plastic chips using compressed air!
There is a risk of eye injuries and loss of eyesight!
Do not pick up sharp-edged metal chips with your bare hands!
Risk of injury! Wear protective gloves!
Remove chips from on and around the machine.
Use a wire brush to remove chips from and clean the clamping chuck, the thread-tapping jaws of the thread-
tapping head and the internal deburrer.
Use a cloth to wipe thread-tapping oil splashes from the machine and the workplace.
6

Maintenance and inspection

All machines are subject to natural wear during use.
They must be maintained from time to time and wear parts must be replaced.
This work may only be carried out by an authorised ROTHENBERGER service station.
This gives you a full warranty on the material and workmanship!
If the machine is being cleaned, maintained, inspected or repaired , it is essential to
switch it off and to pull out the mains plug (de-energised operation)!
Always avoid uncontrolled starting-up of the machine. Risk of injury and accidents!
6.1

Changing the internal deburrer blade

Always wear protective gloves when replacing the blades!
Risk of cuts and injury!
Lift the pipe cutter and the thread-tapping head and pull the internal deburrer towards you.
Remove the spring pin out of the next of the reamer blade.
The reamer blade is released when you pull the reamer blade holder forwards.
Fit a new reamer blade.
Put the previously removed spring pin back into the hole of the new reamer blade.
44
