6.2

Changing the pipe cutter cutting wheel

Always wear protective gloves when replacing the blades!
Risk of cuts and injury!
Bring the pipe cutter into an upright position and lower the thread-tapping head.
Pull off the cotter pin upwards.
Hold the cutting wheel and push the cutting wheel straight pin slowly out on the opposite side.
Cutting wheel
straight pin
Cutting wheel
Remove chips, dirt, oil etc. from the pin and grease the groove.
Insert a new cutting wheel into the blade holder and insert the pin again.
Insert a new cotter pin into the cutting wheel straight pin and secure it by bending it apart.
Remove cotter
pin
Cotter pin
