5.8

Setting the thread length

The thread length was set by the manufacturer but can be changed if required.
Hold set pin with a slot screwdriver and loosen hex nut.
Turning set pin toward „E", makes shorter threads and turning toward „F" makes longer threads. The thread
length will be changed about 2mm by half turn.
Hold set pin with a slot screwdriver not to turn it and tighten hex nut.
5.9

Setting the thread depth

Set location plate to location block which is not fort he size to be adjusted.
Loosen the screw and move location block to adjust the thread depth.
Sliding toward „G" makes deeper threads and sliding toward „H" makes shallower threads The thread depth
will change 1,5 to 2 mm threads by one scale.
With the aid of a measuring instrument, check the cut pipe for a tapered thread etc. and correct the setting if
necessary.
43
