11.3- Technical characteristics for ISR receiver and
transceiver receiver module IST
Housing
ISRS receiver power supply
ISRA receiver / IST
transceiver power supply
Number of output
Type of output
Antenna
Tuner sensitivity
Fuse protection
Response time of an output
when an input is activated
or deactivated (continuous
or intermittent radio
transmission mode)
Passive shutdown time
(radio jamming)
FR
- 94 -
Material : ABS
Color : Yellow (ISRS) or Gray (ISRA/IST)
Tightness : IP65
Dimensions (w/out CG and antennas):
ISRS = 92 x 123 x 50 mm
ISRA/IST = 240 x 120 x 100 mm
Weight :
ISRS : 350 g / ISRA : 1,2 kg / IST : 1,3 kg
DC :
12VDC (9 to 20VDC)
24VDC (20 to 75VDC)
DC :
12VDC (9 to 20VDC)
24VDC (20 to 28VDC)
ISRS : 4 + 1 «Radio quality»
ISRA/IST : 8 + 1 «Radio quality»
Relays with 1 NO contact
Fixed (standard) or BNC external type
ref.: VUB084 with kit ref.: OWR01
< 2μV
2 fuses on electronic support (rated in
accordance with power supply voltage and
receiver models; see "fuse characteristics
and rating section")
1mW mode (not available for IST) : < 60ms
10mW mode : < 500ms
2 s. on a function relay
1.9 s. on the «Radio quality» relay (RM)
EN DE
AC :
24VAC (+10%/-15%)
48VAC (+10%/-15%)
AC :
24VAC (+10%/-15%)
48VAC (+10%/-15%)
