11 - Appendices

11.1- Radio characteristics

Transmit frequency bands
Modulation
Radio channels
Effective radiated power
Average range (1)
(1) = Range will vary according to environment conditions of transmitter and reception
antenna (metal frameworks, walls ... ). The range will be decreased if one of the
products is mounted on a moving equipment.
(2) = 1mW mode not available for IST transceivers
11.2- Technical characteristics for ISE transmitter and
transceiver transmitter module IST
Housing
Power supply
consumption (see next section
for transceiver IST).
Number of available input
FR
- 92 -
ISM 433-434Mhz
FM
18 user-programmable
Steps 100KHz from 433,1 to 434,7MHz,
the 18th 434,740MHz
ISE/ISR : 1mW or 10mW depending selection
IST : 10mW
In unobstructed area (1mw) : 200m (2)
In unobstructed area (10mw) : 350m
In typical industrial environment (1mW) : 80m (2)
In typical industrial environment (10mW) : 100m
Material : ABS
Color : Yellow (ISE) or Gray (IST)
Tightness : IP65
Dimensions (w/out CG and antennas):
Weight : 270 g
Type : DC
Range : 9V to 30VDC
min. = 100 mA
max. = 200 mA
by active input = 12 mA
8
EN DE
ISE : 92 x 123 x 50 mm
IST : 120 x 240 x 100 mm
