Control
70 %
A
100 %
70 %
0 %
No. Designation
A
PWM signal
B Duty cycle
C Brightness
Tab. 7: Analog dimming, example.
6.4

Flashing

Precondition: The luminaire is equipped
with a plug with the pin assignment Type C.
CAUTION
Risk of injury caused by strobe effect.
Risk of injury caused by moving objects,
which are perceived either as slow or
non-moving due to the flashes.
X Before touching lit objects, make sure
that the lit objects are at standstill.
30 %
Photosensitive seizures caused by
flashlight.
Flashlight can trigger epileptic seizures
B
in persons who are at risk.
X Should any symptoms such as dizzi-
C
A PWM signal is applied to pin no. 2 for
flashing. The flashing frequency and flash
duration of the luminaire are regulated by
means of the frequency and duty cycle of
the PWM signal.
NOTES:
ƒ
ƒ
ƒ
ƒ
X Set the required frequency of the PWM
X Define the required flash duration.
X Set the required duty cycle.
CAUTION
ness, altered perception, eye or mus-
cle twitching, trembling on arms and
legs, disorientation, confusion and
short-term loss of consciousness
occur, the person affected must
remove themselves immediately
from the light source and a physi-
cian must be consulted.
The maximum flashing frequency is
500 Hz (period of oscillation 2 ms).
The minimum flash duration is 300 µs.
The duty cycle is calculated according
to the following formula:
Duty cycle [%] = 100 % − Flash dura-
tion [%]
The flash duration of 30 % leads to a
lighting intensity of 30 %.
signal.
ENG
25
