Parts List
6
Ersatzteileliste
Parts List
Parts #
Qty
Description
6274
1
PRECUT FOAM BUMPER GRAY (RS4)
6543
2
RACING SHOCK SPRING 14x25x1.5mm 6.5COILS(SIL)
6544
2
RACING SHOCK SPRING 14x25x1.5mm 6 COILS(GOLD)
6820
8
SILICONE O-RING P-3 (CLEAR)
61051
1
39 TOOTH PULLEY (ONE-WAY)
61059
1
CYCLONE WORLD CHAMPION DECAL
61092
4
WHEEL NUT M4 SERRATED (PURPLE)
61148
1
DIFF THRUST WASHER 2.8x5.8x1mm
61149
1
DIFFERENTIAL THRUST BALL 1/16"
61237
1
BEARING HOLDER PARTS
61246
2
TURNBUCKLE 3x24mm
61247
2
TURNBUCKLE 3x34mm
61284
1
BATTERY TRAY
61287
1
LOW MOUNT SHOCK TOWER (FRONT)
61319
1
PIVOT BLOCK FR (PURPLE)
61320
1
PIVOT BLOCK RF (PURPLE)
61321
1
STEERING ARM SET (PURPLE)
61324
1
SPUR GEAR HUB (PURPLE)
61327
2
CYLINDER UPPER CAP (PURPLE)
61328
2
CYLINDER LOWER CAP (PURPLE)
61338
1
44mm ALUMINUM UNIVERSAL DRIVE SHAFT (PURPLE)
61627
2
DIFF RING
61667
4
O-RING P-8 (BLACK)
66492
1
CENTER PULLEY 18T
66493
1
FRONT BELT 510 (170T)
66494
1
REAR BELT 189 (63T)
67702
1
MAIN CHASSIS 2.5mm W/BATTERY TRAY
67703
1
UPPER DECK 2.0mm
67704
1
FRP MIDDLE BLOCK DECK 2.0mm
67705
1
LOW MOUNT SHOCK TOWER (REAR)
67706
1
FRONT BULK HEAD SET (PURPLE)
67708
1
REAR BULK HEAD SET (PURPLE)
67710
1
MOTOR MOUNT (PURPLE)
67711
1
MIDDLE BLOCK (RIGHT/PURPLE)
67712
1
UPPER BULK HEAD SET (PURPLE)
67714
1
2 WAY DIFF (ONE-WAY/SPOOL)
67715
2
2 WAY DIFF CUP JOINT
67716
2
SHOCK BODY
67717
1
GRAPHITE SUSPENSION ARM SET
67718
1
SWAY BAR HOLDER
67721
1
39T PULLEY (PRO SPEC BALL DIFF)
67723
1
CUP JOINT (POM/PRO SPEC BALL DIFF)
67725
1
DIFF SCREW SET (PRO SPCE BALL DIFF)
67729
1
DIFFERENTIAL BALL 3.0mm (12PCS BAG)
72111
10
SHIM SET 3X5mm (M3X5X0.1-0.2-0.3mm)
73507
1
CARBON GRAPHITE BLOCK AND HUB SET
73508
1
STEERING PARTS SET
73510
1
SHOCK PARTS/BALL END SET
73513
1
BUMPER/BODY POST SET
73518
1
CARBON GRAPHITE C HUB SET (4 DEGREES)
73523
4
BLADDER 12x3.5mm (FLAT TYPE)
75106
20
BODY CLIP (6mm/BLACK)
75115
4
BALL STUD 4.3x10.3mm (2mm SOCKET)
75116
4
BALL STUD 4.3x13mm (2mm SOCKET)
75119
2
SUSPENSION SHAFT 2.5x24.5mm
75121
4
PIVOT BALL 3x5mm
75122
4
STEERING BLOCK BUSHING
75129
5
REBOUND FOAM
75143
1
SERVO SAVER SET
75161
1
PIVOT BLOCK (2.5 DEGREES/ALUMINUM/PURPLE)
75162
1
PIVOT BLOCK (3 DEGREES/ALUMINUM/PURPLE)
75187
2
UNIVERSAL AXLE
75188
2
UNIVERSAL Rebuild KIT
76600
1
SPUR GEAR 100 TOOTH (DELRIN/64PITCH)
A165
2
SPRING 6x7x1.5mm (DIFFERENTIAL) BLACK
A302
8
HEAVY-DUTY BALL CUP 4.3x18mm
B012
2
BALL BEARING 3x6x2.5mm (FLANGED)
B015
2
BALL BEARING 4x7x2.5mm
B017
2
BALL BEARING 4x8x3mm
B020
2
BALL BEARING 5x8x2.5mm
B021
2
BALL BEARING 5x10x4mm
B030
2
BALL BEARING 10x15x4mm
HB70712
2
SHAFT 3x45mm (CYCLONE)
HB70716
1
ANTENNA POST (CYCLONE)
HB70720
2
CYLINDER NUT (BLACK)
HB70721
2
SHOCK SHAFT 28mm
HB70722
2
SHOCK PISTON (1.2mm)
HB70723
2
ROD GUIDE
HB70736
1
SWAY BAR 1.4mm (CYCLONE)
HB70740
1
LOGO DECAL (CYCLONE)
HB70742
4
ALUMINUM HEX HUB SET (CLAMP TYPE/CYCLONE)
HB70743
1
CENTER SHAFT (DIRECT) (CYCLONE)
Z082
10
FLAT HEAD SCREW M3x8mm (HEX SOCKET)
Z083
10
FLAT HEAD SCREW M3x10mm (HEX SOCKET)
Z150
1
ANTENNA PIPE SET
Z155
1
DIFFERENTIAL LUBE (SILICONE)
Z156
1
GRAY DIFFERENTIAL LUBE (FOR DIFF SMALL BALLS)
Z203
10
WASHER M3x6mm
Z234
10
CAP HEAD SCREW M2x5mm
Z242
20
E CLIP E2mm
Z264
10
PIN 2x10mm SILVER
Z350
10
BUTTON HEAD SCREW M3x5mm (HEX SOCKET)
Z352
10
BUTTON HEAD SCREW M3x8mm (HEX SOCKET)
Z353
10
BUTTON HEAD SCREW M3x10mm (HEX SOCKE)
Z354
10
BUTTON HEAD SCREW M3x12mm (HEX SOCKET)
Z356
10
BUTTON HEAD SCREW M3x18mm (HEX SOCKET)
Z653
6
NUT M3
Z676
4
LOCK NUT M3 THIN TYPE
Z700
6
SET SCREW M3x3mm
Z724
6
SET SCREW M4x8mm (ROUND POINT)
Z775
6
SET SCREW TP3.2x5mm
Z814
10
ALUMINUM WASHER 3x6x0.75mm (PURPLE)
Z817
10
ALUMINUM WASHER 3x6x2.0mm (PURPLE)
Z852
10
WASHER 5x7x0.2mm)
Z891
10
WASHER 10x12x0.1mm (COPPER)
Z892
10
WASHER 10x12x0.2mm
Z901
1
ALLEN WRENCH 1.5mm
Z904
1
ALLEN WRENCH 2.0mm
Z950
1
CROSS WRENCH (SMALL)
Z960
1
TURNBUCKLE WRENCH
Liste de pièces
パーツリスト
Ersatzteileliste
Nummer Anzahl Beschreibung
6274
1
Angepasster Rammer grau RS4
6543
2
DAEMPFERFEDER RACING 14x25x1.5mm 6.5Wdg. (SIL)
6544
2
DAEMPFERFEDER RACING 14x25x1.5mm 6Wdg. (GOLD)
6820
8
SILIKON O-RING P-3 (TRANSPARENT)
61051
1
RIEMENRAD 39Z (FREILAUF) CYCLONE
61059
1
CYCLONE WORLD CHAMPION DECALS
61092
4
RADMUTTER M4 (GERIFFELT/LILA/4ST)
61148
1
DRUCKLAGERSCHEIBEN 2.8x5.8x1mm
61149
1
DRUCKLAGERKUGELN 1/16
61237
1
LAGERHALTER TEILE (CYCLONE S)
61246
2
SPURSTANGE 3x24mm (CYCLONE S)
61247
2
SPURSTANGE 3x34mm (CYCLONE S)
61284
1
AKKUHALTER (CYCLONE TC)
61287
1
DAEMPFERBR. (NIEDRIGE B/VORNE/CYCLONE)
61319
1
QUERLENKERHALTER VORNE (LILA) CYCLONE
61320
1
QUERLENKERHALTER HINTEN (LILA) CYCLONE
61321
1
LENKHEBEL SET (LILA) CYCLONE
61324
1
HAUPTZAHNRAD HALTERUNG (LILA)
61327
2
DAEMPFERKAPPE OBEN (LILA) CYCLONE
61328
2
DAEMPFERKAPPE UNTEN (LILA) CYCLONE
61338
1
ALUMINIUM KARDAN 44MM (LILA) CYCLONE
61627
2
DIFFSCHEIBEN
61667
4
O-RING P-8 (SCHWARZ)
66492
1
RIEMENRAD MITTELWELLE 18Z (CYCLONE)
66493
1
RIEMEN VORNE 510 (170Z/CYCLONE)
66494
1
RIEMEN HINTEN 189 (63Z/CYCLONE)
67702
1
CHASSIS 2.5mm (MIT AKKUHALTER/CYCLONE TC)
67703
1
OBERDECK 2.0mm (CYCLONE TC)
67704
1
OBERDECK MITTE (FRP/2.0mm/CYCLONE TC)
67705
1
DAEMPFERBR. (NIEDRIGE B/HINTEN/CYCLONE)
67706
1
DIFFGEHAEUSE SET VORNE (LILA/CYCLONE TC)
67708
1
DIFFGEHAEUSE SET HINTEN (LILA/CYCLONE TC)
67710
1
MOTORHALTER (LILA/CYCLONE TC)
67711
1
MITTELBLOCK (RECHTS/LILA/CYCLONE TC)
67712
1
OBERES DIFFGEHAEUSE SET (LILA/CYCLONE TC)
67714
1
2 WAY DIFF (FREILAUF/SPOOL/CYCLONE TC)
67715
2
2 WAY DIFF CUP JOINT (CYCLONE TC)
67716
2
DAEMPFERGEHAEUSE (CYCLONE TC)
67717
1
SCHWINGEN SET (KOHLEFASERVERSTAERKT/CYCLONE TC)
67718
1
STABILISATOR HALTER (CYCLONE TC)
67721
1
RIEMENRAD 39Z (PRO SPEC DIFF)
67723
1
DIFFERENTIAL CUP JOINT SET (POM/PRO SPEC DIFF)
67725
1
DIFFERENTIAL SCHRAUBE M2.6x31mm (PRO SPEC DIFF)
67729
1
DIFFERENTIAL KUGEL 3.0mm
72111
10
BEILAGSCHEIBENSET 3x5mm (0.1-0.2-0.3mm)
73507
1
LENKHEBEL/TRAEGER (KOHLEFASERVERSTAERKT)
73508
1
LENKUNGSTEILE
73510
1
DAEMPFERTEILE/KUGELKOPF SET
73513
1
RAMMER/KAROSSERIEHALTER SET
73518
1
LENKHEBELTRAEGER (4 GRAD/KOHLEFASERV.)
73523
4
DAEMPFERMEMBRAN 12x3.5mm (FLACH)
75106
20
KAROSSERIEKLAMMERN (6mm/SCHWARZ)
75115
4
KUGELKOPF 4.3X10.3mm (2mm INBUS/4ST)
75116
4
KUGELKOPF 4.3x13mm (2mm INBUS/4ST)
75119
2
ACHSSTIFTE 2.5x24.5mm
75121
4
KUGELKOPF 3x5mm
75122
4
LENKUNGSLAGER
75129
5
REBOUND SCHAUMSTOFF
75143
1
SERVOSAVERSATZ
75161
1
QUERLENKERHALTER (2.5 GRAD/ALU/LILA)
75162
1
QUERLENKERHALTER (3 GRAD/ALU/LILA)
75187
2
KARDAN ACHSE (2ST/PRO4/CYCLONE)
75188
2
KARDAN WARTUNGS SET (2ST/PRO4/CYCLONE)
76600
1
HAUPTZAHNRAD 100 ZAEHNE (DELRIN/64dp)
A165
2
DIFF-FEDER 6X7X1.5mm SCHWARZ
A302
8
KUGELPFANNE 4.3X18mm
B012
2
KUGELLAGER 3x6x2.5mm (MIT FLANSCH)
B015
2
KUGELLAGER 4x7x2.5mm
B017
2
COMPETITION LOW FRICTION KUGELLAGER 4X8X3mm
B020
2
COMPETITION LOW FRICTION KUGELLAGER 5X8X2.5mm
B021
2
COMPETITION LOW FRICTION KUGELLAGER 5X10mm
B030
2
COMPETITION LOW FRICTION KUGELLAGER 10X15X4mm
HB70712
2
ANTENNENHALTER (CYCLONE)
HB70716
1
STABILISATOR (1.4mm/CYCLONE)
HB70720
2
DAEMPFERMUTTER (SCHWARZ)
HB70721
2
KOLBENSTANGE 28mm
HB70722
2
KOLBENPLATTE (1.2)
HB70723
2
KOLBENFUEHRUNG
HB70736
1
STABILISATOR (1.4mm/CYCLONE)
HB70740
1
AUFKLEBER SET CYCLONE
HB70742
4
ALU FELGENMITNEHMER ZUM KLEMMEN (CYCLONE)
HB70743
1
STARRE MITTELWELLE (CYCLONE)
Z082
10
SENKKOPFSCHRAUBE M3x8mm (INBUS)
Z083
10
SENKKOPFSCHRAUBE M3x10mm (INBUS)
Z150
1
ANTENNENROHRSET
Z155
1
DIFFERENTIAL FETT
Z156
1
GRAUES DIFFERENTIALFETT
Z203
10
M3X6 UNTERLAGSCHEIBE
Z234
10
INBUSSCHRAUBE M2x5mm
Z242
20
E-CLIP E2mm SILBER
Z264
10
STIFT 2X10mmSILBER
Z350
10
FLACHKOPFSCHRAUBE M3x5mm (INBUS)
Z352
10
FLACHKOPFSCHRAUBE M3x8mm (INBUS)
Z353
10
FLACHKOPFSCHRAUBE M3x10mm (INBUS)
Z354
10
FLACHKOPFSCHRAUBE M3x12mm (INBUS)
Z356
10
FLACHKOPFSCHRAUBE M3x18mm (INBUS)
Z653
6
MUTTER M3
Z676
4
STOPPMUTTER M3 (FLACH)
Z700
6
MADENSCHRAUBE M3x3mm
Z724
6
MADENSCHRAUBE M4x8mm
Z775
6
MADENSCHRAUBE TP3. 2x5mm
Z814
10
ALUMINIUM UNTERLAGSCHEIBE 3x6x0.75mm (LILA)
Z817
10
ALUMINIUM UNTERLAGSCHEIBE 3x6x2.0mm (LILA)
Z852
10
UNTERLAGSCHEIBE 5x7x0.2mm
Z891
10
UNTERLAGSCHEIBE 10x12x0.1mm (KUPFER)
Z892
10
UNTERLAGSCHEIBE 10x12x0.2mm
Z901
1
INBUSSCHLUESSEL 1.5mm
Z904
1
INBUSSCHLUESSEL 2.0mm
Z950
1
KREUZSCHLUESSEL KLEIN
Z960
1
SPURSTANGENSCHLUESSEL
40
