5
For Non-Ducted Recirculation
Attach each
charcoal
filter to the
black grid on
each side of
the blower.
Press the
charcoal
filter tightly
to the black
grid on the
blower side
and rotate
the filter
clockwise (towards the front of the insert hood)
until it locks into place. Turn counterclockwise
(towards the back of the insert hood) to remove.
Replacing Activated Charcoal Filter
The Activated Charcoal Filters are not washable
and cannot be regenerated, and should be
replaced approximately every 4 months of
operation, or more frequently with heavy usage.
Remove the charcoal filter by rotating it
clockwise (backwards) until it unlocks from the
motor housing and pull off sideways.
To reinsert each charcoal filter, place up against
the side of the blower and push it inward. Then
turn the charcoal filter clockwise (forward) until it
fits into place.
Required Activated Charcoal Filter
Accessory - sku # - FILTER1
(purchased separately).
When used in recirculation mode,
to Reduce the Risk of Fire and
Shock use only conversion kit
Model FILTER 1.
14
Option
1
2
6
Hook the Grease rail (8) positioning it inside
the hood. Is possible wash and reposition
inside the hood.
7
9e
6
7
Baffle Filter
Before putting the filters (6), tighten the 2 knobs
(7) with 2 screws (9e).
Use two hands to insert and remove the filters.
8
9e
7
