7 Working with the FCU

7.1 Online measurement

7.1.1 "Measurement" mode

MODE-key
M1: Measure
M2: Measure+switch
M3: Filter to
M4: Filter from to
M5: Rinse BS
M6: Bottle sampler
Description:
Mode M1 can be used to measure the oil cleanliness without using control functions.
Typical application:
Short-term measurement of the system cleanliness to ISO or NAS standards
Operation:
Start measurement:
ok
start
