3.2. Vertical wall-mounted water heaters, 150 l and 200 l
567
150 l
Dimension
1177 1497
A
88 88
Installation




567
 3/4" hot water branch connection
200 l
3/4" cold water branch connection

Electrical connection box

 Control screen
Electric backup & mechanical safety device location;

position of the middle tank sensor
 Position of middle tank sensor
 Connection refrigerant lines (inlet: 3/8", outlet: 1/4")

230
Use
440



