Safety Information
Technical Data
RC3068 RC3268 RC3278 RC3678
Air inlet thread size (") 1/4
BSPP
Free speed (rpm) 280
Max. torque (Nm) 45
Max. working torque 30
(Nm)
Square drive (") 1/4
Weight (kg) 0.67
RC3068 RC3268 RC3278 RC3678
Sound pressure level 92.9
(dB(A))
Vibration (m/s²) 8.5
Declarations
EU Declaration of Conformity
We, Desoutter GmbH, Edmund-Seng-Str. 3-5,
63477 Maintal, Germany, declare under our sole
responsibility that the product (with name, type,
and serial number, see the front page) is in con-
formity with the following Directive (s):
2006/42/EC (17/05/2006)
Harmonized standards applied:
EN ISO 11148-6:2012
Authorities can request relevant technical infor-
mation from:
Pascal Roussy, R&D Manager, Ets Georges Re-
nault, 38 rue Bobby Sands, BP10273 44818
Saint Herblain, France
Saint-Herblain, 07/10/2022
Pascal ROUSSY
UK Declaration of Conformity
We, Desoutter GmbH, Edmund-Seng-Str. 3-5,
63477 Maintal, Germany, declare under our sole
responsibility that the product (with name, type
and serial number, see front page) is in conform-
ity with the following UK Regulation(s):
Supply of Machinery (Safety) Regulations 2008
Designated Standards applied:
EN ISO 11148-9:2011
Saint-Herblain, 21/01/2022
Pascal ROUSSY
Authorities can request relevant technical information from:
UK Authorized Representative:
Air Compressors & Tools Ltd
6
1/4 1/4 1/4
BSPP BSPP BSPP
280 190 190
50 100 100
25 60 60
3/8 3/8 1/2
0.68 1.22 1.23
92.9 89.2 89.2
8.5 9.2 9.2
Signature
Signature
© Rodcraft - 8956001776
Zodiac – Unit 4, Boundary way
Hemel Hempstead Industrial Estate, HP27SJ Hempstead
Hertfordshire – UK
Contact: M.Taylor
Noise and vibration
Uncertainty 3 dB(A), in accordance with ISO 15744. For
Sound power level, add 11 dB(A)
Vibration standard : ISO-28927-2
These declared values were obtained by laboratory type test-
ing in accordance with the stated standards and are suitable
for comparison with the declared values of other tools tested
in accordance with the same standards. These declared values
are not adequate for use in risk assessments and values mea-
sured in individual work places may be higher. The actual ex-
posure values and risk of harm experienced by an individual
user are unique and depend upon the way the user works, the
workpiece and the workstation design, as well upon the expo-
sure time and the physical condition of the user.
We, Desoutter GmbH, cannot be held liable for the conse-
quences of using the declared values, instead of values re-
flecting the actual exposure, in an individual risk assessment
in a work place situation over which we have no control.
This tool may cause hand-arm vibration syndrome if its use is
not adequately managed. An EU guide to managing hand-arm
vibration can be found by accessing
index.php and selecting 'Tools' then 'Legislation'.
We recommend a programme of health surveillance to detect
early symptoms which may relate to noise or vibration expo-
sure, so that management procedures can be modified to help
prevent future impairment.
If this equipment is intended for fixtured applications:
The noise emission is given as a guide to the machine-
builder. Noise and vibration emission data for the com-
plete machine should be given in the instruction manual
for the machine.
Additional Vibration Information
This tool may cause hand-arm vibration syndrome if its
use is not adequately managed.
This additional vibration information may be of assistance to
employers in meeting their obligations (for example under EU
Directive 2002/44/EC) to assess the risks to their workers
arising from hand arm vibration associated with the use of
this tool.
Ratchet wrenches are suitable for assembly and disassembly
operations in confined spaces.
• The declared vibration value can be used to estimate vi-
bration during rundown. Continuous ratcheting against a
run-down bolt may produce a vibration emission in the
2 2
range m/s to m/s (vibration total values).
• Only use this tool for work which other types of
wrenches, which present lower vibration risks, are unable
to perform satisfactorily.
RATCHET WRENCH
