2.1 Accessories included

The following parts are supplied with Sololift+ D-3 for
the installation. The letters will be used when
describing the installation.
A
C
D
Fig. 2

2.2 Dimensions

The following dimensional sketches show the dimensions of Sololift+ D-3.
Fig. 3
I
J
K
L
295.3
Quantity Description
Rubber sleeve for connection of
1
cabinet shower (∅40)
Metal clips for for connection of
6
cabinet shower and discharge
elbow
Discharge elbow with non-
1
return valve
Rubber sleeve for additional
1
connection (∅40/∅32)
1
Valve cover
2
Screws for floor fittings
2
Floor fittings
Pos.
A
C
D
I
J
K
L
162
7
