Front Panel Menu Reference

Press the Menu key to access the front panel menus. For a brief tutorial, refer to
menu. If a menu item is grayed-out, it is not available for the model that is being programmed.
1st Menu Level 2nd Level
Output Voltage
Current
Mode
Sequence
Advanced
Measure Sweep
Window
Control
AhWh
Transient Mode
Step
List
Arb
Keysight RP7900 Series Operating and Service Guide
3rd & 4th Levels
Programs output voltage settings
Programs output current settings
Programs output priority mode
Delay Programs output on/off delay
Couple Configures output state coupling
Slew Programs output current or voltage slew rates
Resistance Programs output resistance
Bandwidth Current Programs current bandwidth
Voltage Programs voltage bandwidth
Tmode Programs output turn-on/turn-off mode
CurrSharing Enables/disables output current sharing
Configures measurement sampling
Select measurement window
Initiates, triggers, and aborts acquisitions; displays trig state
Measures or resets amp-hours and watt hours
Selects voltage and current transient modes
Configures voltage or current steps and trigger signals
Pace Specifies Dwell or Trigger paced list
Repeat Specifies number of list repetitions, or continuous list
Terminate Specifies list termination conditions
Config Configures individual list step settings
Reset Aborts the list and resets all list settings
Repeat Specifies number of Arb repetitions, or continuous Arb
Terminate Specifies Arb termination conditions
Config Configures individual Arb settings
1 Quick Reference
Use the front panel
Description
