5 SCPI Programming Reference
[SOURce:]CURRent:SLEW[:IMMediate] <value>|MIN|MAX|INFinity
[SOURce:]CURRent:SLEW[:IMMediate]? [MIN|MAX]
Sets the current slew rate. The slew rate is set in amps per second and affects all programmed
current changes, including those due to the output state turning on or off. The slew rate can be set to
any value between 0 and 9.9E+37. For very large values, the slew rate will be limited by the unit's
listed programming speed and bandwidth. The keywords MAX or INFinity set the slew rate to
maximum.
Parameter
0 – 9.9E+37, *RST MAX
Sets the output slew rate to 1 A per second: CURR:SLEW 1
The query returns the value that was sent. If the value is less than the minimum slew rate, the min-
l
imum value is returned. The slew setting resolution is the same as the minimum value, which can
be queried using CURRent:SLEW? MIN. The exact value varies slightly according to calibration.
[SOURce:]CURRent:SLEW:MAXimum 0|OFF|1|ON
[SOURce:]CURRent:SLEW:MAXimum?
Enables or disables the maximum slew rate override. When enabled, the slew rate is set to its
maximum value. When disabled, the slew rate is set to the immediate value set by the
CURRent:SLEW command. Use CURRent:SLEW? MAX to query the maximum slew rate that was set.
Parameter
0|OFF|1|ON, *RST ON
Enable the maximum slew rate: CURR:SLEW:MAX ON
The CURRent:SLEW:MAX command is coupled to the CURRent:SLEW command. If
l
CURRent:SLEW sets the rate to MAX or INFinity, CURRent:SLEW:MAX is enabled. If the slew rate
is set to any other value, CURRent:SLEW:MAX is disabled.
198
Typical Return
<max value>
Typical Return
0 or 1
