Operating Instructions – ZM-SKS
Module for the connection of a SKS rail
Assembling Instructions in Board Plate AS 210:
Insert board plate ZM-SKS in plug-in rail X7. Equipped side must show to the direction of
the transformer.
Jumper J2 – Automatic remove downwards
plugged in =
open =
Jumper J3 – SKS choice
plugged in =
open =
LED H1 – SKS
Permanent illumination = SKS OK
Flashing =
J3 - Jumper
SKS choice
J2 - Jumper
Automatic remove downwards
Automatic remove downwards
no automatic remove downwards
optoelectronic rupturing strip
8,2 kOhm
SKS Disturbance
21
ENGLISH
H1 - LED
SKS
Revision_11_2007
