OPERATING INSTRUCTIONS – AS 210
MOTHERBOARD AS 210
Terminal strip for external radio transmission
Plug-in strip for external triple switch
Setting button
CLOSE
Setting button
OPEN
18
Choice of supply voltage
400V/230V
Terminal rail
limit switch and
control switch
Jumper J15
self-locking OPEN
ENGLISH
Terminal rail
supply
Terminal rail
motor
