1.3 Actuator dimensions

1.4 Joystick dimensions

1.4.1 Joystick low profile

A
B
ELECTROMECHANICAL TRIM TABS
Installation and maintenance manual
MTC
273 mm
A
(10.75")
330 mm
B
(13")
72,5 mm (2.85")
page 7
-
MTS
307 mm
(12.09")
364 mm
(14.33")
