Joystick Standard; Tab Technical Features - Ultraflex UFLEX MTT12 Manuel D'installation Et D'entretien

1.4.2 Joystick standard

1.5 Tab technical features

page 8
of 83 -
ELECTROMECHANICAL TRIM TABS
Ø 69,69 mm (2.76")
A inches/mm 9" (229mm)
B inches/mm 9" (229mm) 9" (229mm)
Installation and maintenance manual
Ø 92 mm (3.62")
"STANDARD" ASSEMBLY
12" 12"
(305mm) (305mm)
12"
(305mm)
12"
(305mm)
18"
(457mm)
