4 WIRINGS

4.1 General notes

WARNING
UFLEX is not to be held responsible for possible damages or malfunctions deriving from operation not
workmanlike performed.
The extension power cables supplied by UFLEX are high-quality, saltiness- and oil-resistant cables.
In case an extension power cable is not long enough, replace it with a longer one.
WARNING
The extension cables supplied by UFLEX are highly water-proof to be assembled in places subjected to salty
water sprays.
The electric cable wiring must be performed by skilled staff. The electric connections must be properly
waterproofed to avoid oxidation on conductors.

4.2 Cable identification

The following table allows a quick consultation on the electric conductors and their use
Conductor colour
Red
Black
White/Green
White/Red
Black/Green
Black/Red
Orange
Orange/White
Orange/Black
Blue
Yellow
Grey
Purple
Green
page 16
of 83 -
ELECTROMECHANICAL TRIM TABS
V bat Power positive wire
GND Power negative wire (ground)
STBD+ Starboard actuator power (positive)
PORT+ Port actuator power (positive)
STBD- Starboard actuator power (negative)
PORT- Port actuator power (negative)
KEY Engine key
NSAF- Neutral safety (Negative)
NSAF+ Neutral safety (Positive)
COM Second station connection
UP Second station connection
DOWN Second station connection
LEFT Second station connection
RIGHT Second station connection
Installation and maintenance manual
Use
Conductor
section
AWG 14
AWG 14
AWG 16
AWG 16
AWG 16
AWG 16
AWG 18
AWG 18
AWG 18
AWG 18
AWG 18
AWG 18
AWG 18
AWG 18
