6. Product information

6.4.2 Load data* EPX-II

Fx
Total length
500
(mm)
Version
EPX-II 30 800 N
EPX-II 40 1000 N
* referred to guide carriages (deflection of the guidance unit f=0.5 mm, static, covering the end
elements)

6.4.3 Dynamic load data EPX-II

Type Fx
Compact guide carriage
EPX-II 30 KG 1000
EPX-II 40 KG 1200
Extended guide carriage
EPX-II 30 KG 1000
EPX-II 40 KG 1200
Mx
Speed
Version
EP-II/EPX-II
EP-II/EPX-II

6.5 Emissions

The A-rated equivalent continuous sound pressure level of these linear units is below 85 dB(A).
36
Admissible forces
Fy
500 1000 1500
1400 N 1200 N 700 N
6000 N 3100 N 1800 N
Fy Fz Mx
1100 1100 70
2400 2400 160
1100 1100 70
2400 2400 160
Fy
Bearing Max. spindle speed
Sliding bearing
Ball bearing
Fz
500 1000 1500
650 N 450 N 200 N
2200 N 680 N 220 N
My Mz
85 99
190 220
100 120
250 280
Fz
My
Mz
80 rpm
250 rpm
Admissible torques
Mx My Mz
80 Nm 110 Nm 140 Nm
160 Nm 190 Nm 240 Nm
Fx
