SECTION 4 − SPECIFICATIONS AND INSTALLATION

4-1. Important Information Regarding CE Products (Sold Within The EU)

!
This equipment shall not be used by the general public as the EMF limits for the general public might be exceeded during welding.
This equipment is built in accordance with EN 60974−1 and is intended to be used only in an occupational environment (where the general public
access is prohibited or regulated in such a way as to be similar to occupational use) by an expert or an instructed person.
Wire feeders and ancillary equipment (such as torches, liquid cooling systems and arc striking and stabilizing devices) as part of the welding
circuit may not be a major contributor to the EMF. See the Owner's Manuals for all components of the welding circuit for additional EMF exposure
information.
S
The EMF assessment on this equipment was conducted at 0.5 meter.
S
At a distance of 1 meter the EMF exposure values were less than 20% of the permissible values.

4-2. Serial Number And Rating Label Location

The serial number and rating information is located on the bottom of the machine. Use the rating labels to determine input power requirements and/or
rated output. CE model rating labels will also display the following symbols: CE, CCC, WEEE, and IEC 60974-1. For future reference, write serial
number in space provided on back cover of this manual.

4-3. Specifications

Input Power
Rated Welding
Single-Phase
Output
AC
70A @ 22.8 Volts DC,
100% Duty Cycle
115 Volts Stick
100A @ 24.0 Volts DC,
35% Duty Cycle
100A @ 14.0 Volts DC,
100% Duty Cycle
115 Volts TIG
150A @ 16.0 Volts DC,
30% Duty Cycle
100A @ 24 Volts DC,
100% Duty Cycle
230 Volts Stick
150A @ 26.0 Volts DC,
30% Duty Cycle
100A @ 14.0 Volts DC,
100% Duty Cycle
230 Volts TIG
150A @ 16.0 Volts DC,
30% Duty Cycle
*Sense Voltage For Stick And TIG Lift Arct
Amperes In-
Welding
Max
put At Rated
Amperage
OCV
Load Output,
Range
DC
50/60Hz,
Single-Phase
17.4
69V
20 − 100A
*12-16
26.4
18.4
69V
5 − 150A
*12-16
28.0
13.1
69V
20 − 150A
*12-16
21.6
8.3
69V
5 − 150A
*12-16
14.2
KVA @
Duty
KW
Dimensions
Cycle
2.0
1.9
3.0
3.0
2.1
2.1
3.4
3.1
H: 9 in (229 mm)
W: 5.5 in (140 mm)
L: 13.25 in (337 mm)
3.0
2.8
4.9
4.7
2.0
1.9
3.2
3.1
Weight
13.7 lb
(6.2 kg)
OM-220 340 Page 13
