B. Car seat base
C. Rigid connectors
D. Rigid connector button
E. Rigid connector fastening indicators
F. Side Safety System
V. Top Tether
Fig. B
G. Headrest
H. Backrest
I. Shoulder straps
J. Child car seat restraint harness
K. Buckle
L. Recline lever
M. Seat rotation lever
N. Belt adjustment strap
O. Belt adjustment button
P. Belt guide
Q. Group 2/3 belt guide
R. Mini reducer
Fig. C
S. Headrest adjustment lever
T. Top belt guide
U. Belt slot
V. Top Tether

1.3 PRODUCT FEATURES

GROUPS 0+, 1, 2 and 3 (SEMI-UNIVERSAL).

IMPORTANT WARNING

1. This is a "Semi-universal" child car seat, type-
approved in accordance with ECE Regula-
tion R44/04 and exclusively compatible with
the vehicles specified in the "Vehicle list" that
comes with the product.
2. It is only suitable for vehicles which feature
a 3-point static or 3-point retractable vehi-
cle seat belt approved according to UN/
ECE Regulation No.16, or other equivalent
standards.
3. In case of doubts, contact the manufacturer
of the restraint device or your dealer.
1.4 RESTRICTIONS AND REQUIREMENTS
REGARDING THE USE OF THE PROD-
UCT AND VEHICLE SEAT
WARNING! Follow the restrictions and re-
quirements for use of this product and the
vehicle car seat at all times: safety will not be
guaranteed otherwise.
• This car seat is type-approved for use with
children who weigh between 0 to 36 kg (from
birth until roughly 12 years of age).
• The vehicle seat must be equipped with a
3-point vehicle seat belt, static or with retrac-
tor, type-approved in accordance with UNI/
ECE Regulation No 16 or other equivalent
standards (Figure 1).
WARNING! Never fit the child car seat to a ve-
hicle seat that is only equipped with a 2-point
safety belt (Fig. 2).
• The car seat may be fixed to the passenger
side front seat equipped with ISOFIX anchor-
ages or to any of the rear seats equipped with
ISOFIX anchorages. In the Group 0+ configu-
ration (0-13 kg) the car seat may only be fixed
to the front seat if the airbag has been deac-
tivated. Never use this child car seat on rear-
facing or side-facing car seats (Fig. 3).
• This product is only intended to be used as a
child car seat; it is not meant for use indoors.
• It may happen that the vehicle seat belt
buckle is too long and exceeds the expected
height above the bottom of the car seat (Fig.
4A-4B). In this case the seat must not be fixed
on that seat but must be installed on another
seat on which there is no problem. For more
information, contact your car manufacturer.
WARNING! Group 0+ and Group 1. If it is used
in a vehicle equipped with rear safety har-
nesses with integrated airbags (inflatable seat
belts), the interplay between the inflatable
portion of the seat belt and this child restraint
system could cause serious injury or death. Do
not install this child restraint equipment where
an inflatable safety harness must be used.
WARNING! Group 2/3. When using in vehicles
equipped with rear seat belts with integrated
airbags (inflatable seat belts), follow the car
manufacturer's instruction manual.

2. INSTALLATION

WARNING! The text and figures of these in-
structions refer to the installation of the child
car seat on the right back seat. Follow the
same steps to install the car seat in other posi-
tions.
