Comelit MT KIT 13 Manuel Technique page 32

D
1216
1214KC
B
1205/B
C
A
4875KC
4876KC
Settings Table Art. 1216 according to the type of connection cable used
Type of cable
Double-wire cable
(cross-sect. 0.5 mm 2 Ø 0.8 mm AWG 20)
Double-wire cable (cross-sect. 1.5 mm
Double-wire cable (cross-sect. 1 mm
Twisted door-entry phone pair
(cross sect. 0.28 mm 2 Ø 0.6 mm AWG 23)
Braided and screened cable
(cross-sect. 1 mm 2 Ø 1.2 mm AWG 17)
UTP5 cable cat. 5
(cross-sect. 0.2 mm 2 Ø 0.5 mm AWG 24)
Comelit cable Art. 4576 and Art. 4578 (cross-sect. 0.5
mm 2 Ø 0.8 mm AWG 20)
1216
1214KC
F
F
2 Ø 1.4 mm AWG 15)
2 Ø 1.2 mm AWG 17)
4833C
1205/B
4875KC
4876KC
4875KC
4876KC
Setting Art. 1216
MT KIT 13
E
1212/B
G
1395
2
1
1
2
31
MT KIT 13
