Choose a suitable position for the MonoControl CS, in particular:
– Type plate legible,
– Reset button recognisable and easily accessible,
– Avoid damage during cylinder replacement,
– Make it difficult for gas in the liquid phase to penetrate,
– Route the high-pressure hose without tension,
– Fasten to a stable wall / ceiling with at least 2 screws arranged
diagonally.
Ensure that the MonoControl CS is securely screwed in place.
– Connect the 8 mm or 10 mm diameter gas pipe to the regulator
outlet in accordance with the respective installation instructions for
olive screw connections (e.g. EN ISO 8434-1). When tightening,
carefully use a second spanner on the provided spanner surfaces to
keep the entire assembly from turning (surfaces (1) and (2)). Make
sure that the olive and the tapered seal are in perfect condition.
Figure 3a Figure 3b
