FAULTS / SOLUTIONS

Here below you can find some causes and the possible solutions for some problems that could cause a fail-
ure to start or a bad working of the burner.
A fault usually makes the lock-out lamp light which is situated inside the reset button of the control box
(3, fig. 1, page 1). When lock out lamp lights the burner will attempt to light only after pushing the reset button.
After this if the burner functions correctly, the lock-out can be attributed to a temporary fault. If however the
lock out continues the cause must be determined and the solution found.
FAULTS
The led on the con-
trol box is off and
the burner does not
start.
The green led is on
and the burner re-
mains in the pre-
purge phase.
B u r n e r r u n s n o r-
m a l ly i n t h e p r e -
purge and ignition
cycle and locks out
after 5 seconds ca.
Burner starts with
an ignition delay.
The burner remains
st
in 1 stage.
The burner goes al-
nd
ways in 2 stage.
WARNING
The manufacturer cannot accept responsibility for any damage to persons, animals or property due to error in
installation or in the burner adjustment, or due to improper or unreasonable use or non observance of the tech-
nical instruction enclosed with the burner, or due to the intervention of unqualified personnel.
