110V/230V Electrical system
3.8.1.3
Tecma products with a 110V/230V motor have a plug, which must be connected to the power
supply. Diagrams in section A.3.6.5/6.
Plug
Black/Brown
Black/Blue
Black/Grey
Black/Red
WARNING: electrical systems must be connected by qualified personnel. To choose
the wire section, consider the length and power consumption. (see section 7.0). Use
the connectors provided with the TECMA sanitary system.
NOTE: Install the transformer junction box in a dry and easily inspectable room.

Single and Multiple System - Salt Water

Hydraulic system

3.8.2.1
The flushing cycle of the TECMA marine toilet uses external water via a sea cock. Diagrams
in section A.3.1/2.
When the flushing cycle is started, the control panel starts an inlet pump, which pushes the
water by means of a specific system.
WARNING: The inlet pump is not used as a check valve. This way, water can flow even
when the inlet pump is not running.
WARNING: If the toilet is below the floating line, install a vent valve on the inlet and
flushing system. Consider the heeling in case of sailing boats.
WARNING: The inlet pump is not available for models with 110 V/230 Vac motors.
Tecma S.r.l.
Via Flaminia | Loc. Castello delle Formiche
05030 Otricoli (TR)
ITALY
Main power supply (motor and solenoid valve) - Shuko CEE/ US-Can
transformer/control unit
transformer/control unit
Tank sensor/control unit
transformer/control unit
Design and Flexi Line | instructions for installation and use | ENG
66
