TECHNICAL DATA / DATI TECNICI
A.2
Fuse recommended
Pump performance
Outlet Duck bill valve (male)
Nominal data – when designing the system consider the loss due to 90° elbows and other system particularities.
The system should be as linear as possible.
V
alori nominali – tenere conto delle perdite di carico dovute alle curve a 90° e alle caratteristiche dell'impianto. Mantenere
l'impianto il più lineare possibile
Mantene
Tecma S.r.l.
Via Flaminia | Loc. Castello delle Formiche
05030 Otricoli (TR)
ITALY
MAC 11
12V DC
OUTLET PUMP
40A
110-125V AC
24V DC
30A
71.3 gpm
Max 270L/min
Max vertical head 11mt
Max horizontal distance 90 mt
1.5" / required ID 1.5" (38.5 mm)
147
Design and Flexi Line | APPENDIX
220-240V AC
60Hz 50Hz or 60 Hz
8A 5A
36.1 ft
295.3 ft
