Servicing the Air Filter

WARNING
Fuel and its vapors are extremely flammable and
explosive.
Fire or explosion can cause severe burns or
death.
• N ever start or run the engine with the air cleaner
assembly or air filter removed..
NOTICE: Do not use pressurized air or solvents to clean
the filter. Pressurized air can damage the filter and
solvents will dissolve the filter.
1. Remove the fasteners (A, Figure 11) and the air filter
cover (B).
2. To remove the filter (C), lift the end of the filter and
then pull the filter off the intake (D).
3. To loosen debris, gently tap the filter on a hard sur-
face. If the filter is excessively dirty, replace with a new
filter.
4. Wash the pre-cleaner in liquid detergent and water.
Then allow it to thoroughly air dry. Do not oil the pre-
cleaner.
5. Assemble the dry pre-cleaner to the filter.
6. Install the filter on the intake. Push the end of the filter
into the base as shown. Make sure filter fits securely in
the base.
7. Install air filter cover and secure with fasteners.
22
Servicing the Muffler
WARNING
Running engine produces heat. Engine parts,
especially muffler, become extremely hot.
Severe thermal burns can occur on contact.
Combustible debris, such as leaves, grass, brush,
etc. can catch fire.
• A llow muffler, engine cylinder and fins to cool before
touching.
• Remove visible debris from engine compartment.
WARNING
Replacement parts must be the same position as
the original parts or fire could result.
To service the muffler, see an authorized dealer.
Servicing the Spark Plugs
WARNING
Unintentional sparking can result in fire or electric
shock.
Unintentional start-up can result in entanglement,
traumatic amputation, or laceration.
When testing for spark:
• Use approved spark plug tester.
• Do not check for spark with spark plug removed.
CAUTION: Spark plugs have different heat ranges. It is
important that the correct spark plug is used, otherwise,
engine damage can occur.
Clean Spark Plug
Clean with wire brush and sturdy knife. Do NOT use
abrasives (D, Figure 4).
