(10)
(10)
Secure the handle plates and the handle tube
using "Extrude-Tite" screws
3
IMPORTANT! To secure the two handle plates (1) in the centre, place two Extru-
de-Tite screws on one side (9) and two Extrude-Tite screws on the other side
(10), so that the screw heads are each on the side with the larger hole.
4
Operating the
IMPORTANT! When the handle (1) is retracted, it is essential to lock the handle
handle
by turning it to the left.
1
Extend the handle
88
(3)
(4)
(1)
(5)
(9)
(9)
Secure the handle plates (1) to the top using four Extrude-Tite screws (5) and
(7)
Secure the handle plates (1) together in the centre using four Extrude-Tite
screws (9) and (10)
To retract the handle (1):
-
Turn the handle to the left (unlock)
-
Turn the handle to the left again (lock)
(1)
1
(6)
(7)
(8)
2
IMPORTANT! To fix the handle plates
(1) on the top, place two Extrude-Tite
screws on one side (5) and two Extru-
de-Tite screws on the other side (7), so
that the screw heads are each on the
side with the larger hole.
IMPORTANT! When the handle (1) is
extended, it is essential to lock the
handle by turning it to the right.
2
Allow the handle plates (1) to en-
gage on the power source handle
(4) using the locking devices (2)
Insert the cotter pin (8) of the
handle tube (3) into the guides (6)
of both handle plates
To extend the handle (1):
-
Turn the handle to the right
(unlock)
-
Pull the handle out as far as it
will go
-
Turn the handle to the right
again (lock)
