Remember the environment! Do not dispose of used batteries with domestic waste.

Dispose of them at a battery-collection point or as toxic waste. Your local authority will give
you the information you need.

9.4 Fuse replacement

Before opening the BENNING MM 12, ensure that it is not connected to a source of voltage!

Electrical danger!
The BENNING IT 105 is protected against overload by means of an integrated fuse (1.6 A, 1000 V, super-
fast-acting (FF), breaking capacity ≥ 30 kA, D = 6.3 mm, L = 32 mm (part no. 10194027).
Proceed as follows to replace the fuses:
- Turn the rotating switch 1 to "OFF".
- Lay the BENNING IT 105 face down and release the screws of the battery compartment cover.
- Lift the battery compartment cover off the bottom part.
- Laterally lift one side of the defective fuse off the fuse holder by means of a slotted screwdriver.
- Push the defective fuse out of the fuse holder completely.
- Insert a new fuse which has the same rated current, same rated voltage, same breaking capacity, same
triggering characteristics and same dimensions.
- Lock the battery compartment cover into place on the bottom part and tighten the screws.
See figure 8: Fuse replacement
9.5 Calibration
Benning guarantees compliance with the technical and accuracy specifications stated in the operating
manual for the first 12 months after the delivery date.
To maintain the specified accuracy of the measurement results, the instrument must be recalibrated at
regular intervals by our factory service. We recommend a recalibration interval of one year. Send the unit
to the following address:
Benning Elektrotechnik & Elektronik GmbH & CO. KG
Service Centre
Robert-Bosch-Str. 20
D - 46397 Bocholt

9.6 Spare parts

Fuse 1.6 A, 1000 V, superfast-acting (FF), breaking capacity ≥ 30 kA, D = 6.3 mm, L = 32 mm part no.
10194027
10. Environmental notice
At the end of the product's useful life, please dispose of it at appropriate collection points provided
in your country.
04/ 2020 BENNING IT 105

28
