6.
Operating Instructions
6.1. Structure
510
82
Sealing
pincers
12
Compressed air port nipple
135
Tension element
68
Rotary lead through
73
Lifting lever
82
Suspension shackle
6.2. Functional principle
1. Manually lead band through
the sleeve,
2. bend beginning of band,
3. tension by means of transport
wheel,
4. lock by notching the sleeve,
5. cutting the band fed
MAXI II
12
73
103
100
135
99
H 263 EU 22/08
93
92
92
Tension lever
93
Locking lever
99
Guide screw
100
Transport wheel
103
Compressed air motor
510
Cylinder
4
5
1
2
68
3
27 / 55
