Introduction; Warrenty - Becker R8/17PS Notice D'utilisation

Introduction .......................................................................................................................................................................................................................................

Warrenty .............................................................................................................................................................................................................................................
Safety Information ...........................................................................................................................................................................................................................
Observance of the instructions ....................................................................................................................................................................................................
Assembly instructions .....................................................................................................................................................................................................................
Positioning the end limits .............................................................................................................................................................................................................
What to do if... ..................................................................................................................................................................................................................................
Technical Data ...................................................................................................................................................................................................................................
Information for the Electrician ....................................................................................................................................................................................................
Sample wiring diagrams .................................................................................................................................................................................................................
Thank you very much for purchasing this Becker product.
The R8/17PS(+) - R120/11PS(+) tubular drives are high-quality products with numerous performance features:
• Installation without end stops possible (original position to position reached)
• Automatic recognition of end limits by means of intelligent electronics using end stop systems
• No need to adjust end limits: changes to canopies curtains are automatically compensated for using the end stop systems
• Safety shutdown in accordance with European engineering directive (protection against restarting)
• Optimal adjustment of closing mechanism to suit the system
• Low-maintenance operation of system and drive increases service life
• Suitable for awnings, box awnings, screens, drop arm awnings and winter garden shades
• No external limit switch
• Canopy end limits easy to set by pressing a button on the setting controls or using a switch on the drive
• Can be fitted on the left or right
• Several drives can be switched in parallel
• Suitable for all Becker controls
• Compatible with earlier motors (4-wire connecting cable)
Please observe the operating instructions when installing and setting the equipment.
Becker-Antriebe GmbH is released from all guarantee and product liability obligations if the customer modifies the equipment without our prior
approval or if the equipment is installed by the customer or third parties either incorrectly or contrary to the installation instructions specified.
All persons carrying out subsequent processing must ensure that all statutory product manufacturing and maintenance regulations, in particular,
EMV standards, are observed.
This product is subject to technical development and improvements. Please refer to the current sales brochure for the precise product specifica-
tions.
Contents
Introduction

Warrenty

16
Operating Instructions
Page
16
16
17
18
18
20
24
24
25
26
