Latches
1
Control board
2
10. Disconnect the ground wire from the ground wire clip near the top of the rear panel. (See Figure 8.)
2
Ground wire clip
1
11. Gently pull the panels away from the power supply.
Powermax30/Powermax30 XP Field Service Bulletin 805320
Figure 7
4
3
2
Figure 8
1
Magnetics Assembly Replacement
2
Ribbon cable
3
Power board
4
Rear panel
2
3
4
