Maintenance and care
When
Every 4 weeks (depending on
frequency of use)
Every 2-3 months (depending on
frequency of use)
Service:
If you have any questions or need help, please contact your SOPUR dealer, who will be pleased to advise you on matters of service and
repair.
Depending on the use of your Shark/Shark S, we recommend that you contact your dealer at the very least, every 6 months, to have
your Shark/Shark S checked by a specialist.
Tyre maintenance
Tyres
The Shark/Shark S is fitted with special 20''/26''
tyres on the rear wheels and a 26'' drive wheel.
Make sure that you always use the recommended
tyre pressure, as this fundamentally determines the
handling characteristics of the Shark/Shark S. Tyre
pressure that is too low makes movement and
manoeuvring more difficult, as there is increased
resistance to roll and the effort required by the user
is increased.
The optimum tyre pressure for the various tyres is
shown on the tyre walls.
Tyre assembly/repair
Before fitting a new inner tube:
• Check the rim bed and tyre inner wall for foreign
objects and if necessary, clean thoroughly.
• Check the condition of the rim tape, particularly
near the valve opening. Only firm rim tapes which
fit well offer permanent protection against inner
tube damage from burns and sharp-edged spoke
heads.
CAUTION!
After fitting, check the tyre pressure. Correct
tyre pressure and perfect condition of the tyre
are prerequisites to ensure your personal safety
and the performance of your Shark/Shark S.
Pumping up the tyres:
Check on both sides and all the way round that the
inner tube is not trapped between the tyre flange
and the rim. Push the valve back gently and then
pull it out again, so that the inner tube is in the best
position in the area of the valve.
8
SHARK/SHARK S
(9.8)
What
Put a few drops of oil on the fol-
lowing components:
• Drive head
• Brake lever assembly
Grease the transition of the stro-
kes of the gears and brake lever.
Check that all screw connections
are tight!
Oil the drive chain!
Check:
• for cleanliness
• general condition
Note
Carry out yourself or with the help of an assistant.
Before oiling, remove all traces of old oil residue. Be careful that
any surplus oil does not damage the immediate environment (e.g.
your clothes).
Carry out yourself or with the help of an assistant. Spray lightly
with Teflon spray.
Watch your clothes!
Carry out yourself or with the help of an assistant.
If there are tears or general wear and tear, replace the rubbers or
immediately contact an authorised workshop for repair.
Identification plate
Identification plate (11.1)
The identification plate is located on the cross-bra-
ce tube or frame cross tube and on the back page
of the user instructions. The plate contains the
exact model designation and other technical details.
When ordering replacements or making complaints,
please include this information
• Serial number
• Order number
• Month/Year
Guarantee
You have chosen a high-quality Sopur product. We
thank you for this and provide you with a guarantee
of 5 years on all frame parts and the cross-brace,
and 1 year for all other parts. We accepts no liability
for damage caused by improper fitting and/or
repairs or for such work if carried out by unauthori-
sed persons, or for damage caused by neglect and
wear and tear, or by modifications to parts carried
out by the user or third parties. In this case our pro-
duct responsibility is no longer valid.
Customised equipment cannot be exchanged.
Torque settings
Drive head 50 Nm
Caster fork 50 Nm
Steering shaft 50 Nm
M12 nut 50 Nm
Saddle support clamp 10 Nm
M6 screw 10 Nm
M6 nut 10 Nm
The torque for M6 screws is 7 Nm, unless stated otherwise.
20'' pneumatic wheel 10 Nm
Handbar assembly 40 Nm
Drive crank
175 mm M8 10 Nm
Drive crank
185 mm M8 25 Nm
