Power supply voltage
Power supply frequency
Installed power
Absorbed current
PAYMENT SYSTEM
Using special kits, the machine can be fitted with payment
systems with Executive, MDB or BDV protocol.
The payment systems must be housed in the special side
module (optional).
SALE PRICES
A different programmable price can be set for each selec-
tion;
the standard setting has the same sales price for all
selections.
WATER SUPPLY
From the mains, with a pressure of 7.3 to 123.3 psig (0.5
to 8.5 bar).
The machine can be equipped with water supply tanks of
different capacity, housed in an external module or in the
base cabinet.
AVAILABLE ADJUSTMENTS
Time adjustment for water and product doses.
Water temperature adjusted via software.
CONTROLS
- Presence of water
- Operating temperature reached
SAFETY DEVICES
- Main switch
- Door switch
- Top panel switch
- Presence of solid waste tray
- Presence of liquid waste container (FB only)
- Manual-reset boiler safety thermostat
- Instant boiler float jam
- Overflow solenoid valve (only with water supply from
the mains)
- Manual-reset double temperature relief valve for anti-
boiling function
- Timer protection for:
Fresh-brew coffee (tea) doser device
- Overheating protection for:
Doser units
Pump
Electric mixers
- Fuse protection for:
Main electrical circuit
Board power supply transformer
FB board power supply transformer
© by N&W GLOBAL VENDING SpA
All manuals and user guides at all-guides.com
120 V~
CAPACITY OF CONTAINERS
60 Hz
1300 W
11.3 A
POWER CONSUMPTION
The machine power consumption depends on many fac-
tors, such as the temperature and ventilation of the room
where it is installed, the inlet water and boiler temperature,
etc.
With an ambient temperature of 22° C the following power
consumption levels resulted:
To reach operating temperature
For 24 h in stand-by
The above power consumption calculated from average
data should only be taken as an indication.
ACCESSORIES
A wide range of accessories can be installed on the
machine to vary its performance:
The installation kits are supplied with their own installation
and test instructions, which must be strictly observed to
ensure the machine safety.
Important notice!!
The use of kits which are not approved by the manufacturer
of the vending machine does not guarantee compliance
with safety standards, especially for energised parts.
The manufacturer declines all responsibility for the use of
non approved components.
Installation and the following testing operations must
be carried out exclusively by personnel who have a
specific knowledge of the machine functions from a
point of view of electrical safety and health regula-
tions.
4
C
a
p
a
i c
y t
f o
c
o
n
a t
n i
e
s r
g (
a r
m
) s
F
e r
s
h
C
f o
e f
e
M
k l i
C
h
o
c
o
a l
e t
F
e r
s
h
e T
a
F
e r
n
c
h
V -
a
i n
a l l
F
e r
s
h
b
e r
w
9
0
0
1
4
0
0
2
0
0
0
2
3
0
0
2
0
0
0
317.4 W/h
1742 W/h
07 06 275- 00
