FILLER MENU
When pressing once the programming button located on
the push-button card, the machine goes into "Filler menu"
mode.
The display presents the first item of the "filler" menu with
a series of numbers next to it, identifying the level of the
current menu.
Press the confirm button " " to access the menu.
Press the exit button " " to return to the previous menu.
FILL>
STATISTICS
STATISTICS
All data concerning sales and the machine operations is
stored in both total counters and relative counters, which
can be reset without losing total data.
Printing
Connect an RS232 serial printer having a Baud rate of
9600, 8 data bit, no parity, 1 stop bit to the serial port
located on the push button board to print all of the statistics.
The printout will also contain the machine information, the
date and the software version.
To connect the printer, do as follows:
- press the confirm print button " ", displaying the mes-
sage "Confirm?";
- connect the printer before confirming;
- Press the confirm button " " again to start printing.
Displaying
Press the confirm button " " to display in a sequence the
same data obtained with the statistic printing, for both total
and relative counters.
Deleting
Statistics can be reset for relative counters globally (all
types of data) or selectively for:
- selections
- failures
- coin mechanism data
Press the confirm button " ", and the message "Confirm?"
starts blinking.
Press the confirm button " ", the message "Running" is
displayed for a few seconds and all statistics are reset.
© by N&W GLOBAL VENDING SpA
All manuals and user guides at all-guides.com
SELECTION PRICES
This function is used for changing the sales price for each
single selection and for each time band that may be set.
FILL>
FILL>
Print statistics
FILL>
Display statistics
FILL>
CHANGE TUBES CONTROL
Reset statistics
By accessing the "Tube control" function the change tubes
can be filled or released manually.
Confirm refilling, and the display will indicate
"Credit: ——" which is the value of money available in
change the tubes; insert the desired coin into the validator
and the display will indicate the value of money available
in the change tubes.
When confirming releasing, it will be possible to decide
which tube to release. Each time the confirm button " " is
pressed, a coin is ejected from the active tube.
FILL>
FILL>
FILL>
18
PRICES
Tubes control
Fill tubes
Credit:#####
Release tubes
Credit:#####
PRICES
Selection #
Selection #
Time band #
Time band #
Price # #. # #
Release tubes
Tube A ÷ X
07 06 275- 00
