MISCELLANEOUS
This menu contains some sub-menus, used less fre-
quently, which permit control of the functions described
below.
TECH>
MISCELLANEOUS
Machine information
Installation date
This function is used to store the current date of system as
installation date.
The date is printed when retrieving the statistics.
Programming the MACHINE code
When the "Machine code" function is displayed the eight-
digit numeric code identifying the machine can be changed
(from the default 0).
Programming the operator code
When the "Operator code" function is displayed the six-
digit numeric code identifying groups of machines can be
changed (from the default 0).
Initialising
When the "Initialise" function is displayed the vending
machine can be initialised restoring all default data.
This function should be used if there is a memory data error
or when the software is replaced.
Except for the general electronic counter, all statistical
data is reset.
Press the confirm button " " to display the message
"Confirm?". Press the confirm button " " again and some
parameters will be requested, which are:
"Country"
intended as type of base doses for the different selections
(e.g. IT coffee = 45 cc - FR coffee = 80 cc).
The available "countries" vary according to the models.
"Layout"
A number of Button/Selection combinations to
choose from is provided for each model and
dose type (the combinations available for each
layout are indicated in the dose selection table
supplied with the machine).
"Tank"
Defining whether the water supply is:
ON
- from the tank with level sensor
OFF
- from the mains
Equipped base cabinet - from the tank without level sen-
sor
When confirming the options the message "Working" is
displayed for a few seconds.
© by N&W GLOBAL VENDING SpA
All manuals and user guides at all-guides.com
"Language"
When the machine is switched on for the first time or in
any case after initialising, as well as the list of controls
to be performed, also the language used for the mes-
sages on the display is proposed.
The available languages can be scrolled with the " " and
" " buttons, and the selection is confirmed with button " ".
TECH>
Unless the machine is initialised, the language request is
"List of functions"
not made again.
UP-KEY SETUP CONTROL
Up-Key -> vending machine
When confirming this function after inserting the Up-Key in
the special port located on the C.P.U. board, it will be
possible to select the setup file from the list shown on the
display using the scrolling buttons, then when confirming
with the confirm button the selected setup will be loaded in
the vending machine.
Vending machine -> Up-Key
When confirming this function after inserting the Up-Key in
the special port located on the C.P.U. board, it will be
possible to save the setup file to the Up-Key with the
configuration present in that moment in the vending ma-
chine, indicating the name to be assigned to the file (e.g.:
Max000.STP).
Delete
This function is used for deleting one by one the setup files
present in the inserted Up-Key.
Delete all
This function is used for deleting all the setup files present
in the inserted Up-Key.
UP-KEY STATISTICS CONTROL
Vending machine -> Up-Key
When confirming this function after inserting the Up-Key in
the special port located on the C.P.U. board, it will be
possible to save the statistics file to the Up-Key with all of
the statistics files present in that moment in the vending
machine, indicating the name to be assigned to the file
(e.g.: Max000.STA).
Delete
This function is used for deleting one by one the statistics
files present in the inserted Up-Key.
Delete all
This function is used for deleting all the statistics files
present in the inserted Up-Key.
26
07 06 275- 00
