English
Fault Cause

Lawn mower

Blade is damaged.
vibrates
excessively.
Blade is not correctly attached.
Grass is not Blade is blunt or worn.
being cut
cleanly.

19 Specifications

19.1 STIHL RM 2.2 R, RM 2.0 RC
Lawn Mower
– Engine type:
– RM 2.2 R: STIHL EVC 200.3
– RM 2.0 RC: KOHLER HD675
– Displacement:
– RM 2.2 R: 139 cm³
– RM 2.0 RC: 149 cm³
– Power:
– RM 2.2 R: 2.1 kW (2.8 hp) at 2800 rpm
– RM 2.0 RC: 2.2 kW (3.0 HP) at 2800 rpm
– Speed:
– RM 2.2 R: 2800 rpm
– RM 2.0 RC: 2800 rpm
– Maximum fuel tank capacity:
– RM 2.2 R: 0.9 l
– RM 2.0 RC: 1.4 l
– Weight:
– RM 2.2 R: 24 kg
– RM 2.0 RC: 27 kg
– Cutting width:
– RM 2.2 R: 46 cm
– RM 2.0 RC: 46 cm
19.2 Blade
– Minimum thickness a: 2.0 mm
– Minimum width b: 45 mm
– Sharpening angle c: 30°
30
Remedy
Replace blade.
Attach blade.
Sharpen or replace blade.
19.3 Sound Values and Vibration
Values
RM 2.2 R
The K value for the sound pressure level is
2 dB(A). The K value for the guaranteed sound
power level is 1.4 dB(A). The K value for the
vibration value is 3.16 m/s².
– Sound pressure level L
ance with EN ISO 5395-2: 79 dB(A)
– Guaranteed sound power level L
ured in accordance with 2000/14/
EC / S.I. 2001/1701: 92 dB(A)
– Vibration value a
accordance with EN ISO 5395-2: 7.90 m/s²
RM 2.0 RC
The K value for the sound pressure level is
2 dB(A). The K value for the guaranteed sound
power level is 2.1 dB(A). The K value for the
vibration value is 2.20 m/s².
– Sound pressure level L
ance with EN ISO 5395-2: 79 dB(A)
– Guaranteed sound power level L
ured in accordance with 2000/14/
EC / S.I. 2001/1701: 93 dB(A)
– Vibration value a
accordance with EN ISO 5395-2: 4.40 m/s²
For information on compliance with Employers'
Vibration Directive 2002/44/EC and
S.I. 2005/1093, see www.stihl.com/vib.
19.4 REACH
REACH is an EC regulation and stands for the
Registration, Evaluation, Authorisation and
Restriction of Chemical substances.
For information on compliance with the REACH
regulation see www.stihl.com/reach.
19 Specifications
measured in accord‐
pA
meas‐
WAd
, handlebar, measured in
hv
measured in accord‐
pA
meas‐
WAd
, handlebar, measured in
hv
0478-111-9957-A
