electrical data for version without analog input signal:
90° posi-
tioning time
1)
torque
(Specifica-
consumption
tions under
load)
20
12 s
35
7 s
60
12 s
100
23 s
Other positioning times on request
1)
2)
The operating voltage must not drop below 11.5 V
We recommend an actuator designed with 1.5 times the
maximum torque of the fitting (On/Off).
10
power
Voltage / frequency
15 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
45 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
45 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
45 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
english
Type 3003
TechnicalData
electrical data for version with analog input signal:
90° posi-
tioning time
1)
torque
(Specifica-
consumption
tions under
load)
20
25 s
35
40 s
60
79 s
100
119 s
Other positioning times on request
1)
2)
The operating voltage must not drop below 11.5 V
We recommend an actuator designed with 2 times the
maximum torque of the fitting (analog input signal).
power
Voltage / frequency
15 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
45 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
45 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
45 W
15-30 V AC, 50-60 Hz /
12-48 V DC
2)
100-240 V AC, 50-60 Hz /
100-350 V DC
