English - Konrow CHIPO3 Guide D'utilisation

1. Inserting a SIM card
• Turn off the phone and remove the back cover and battery.
• Insert the SIM card correctly in the space provided (see opposite pattern).
You have 2 SIM card ports (SIM1 and SIM2). Be sure to respect the
direction of insertion of the cards.
• Then replace the battery and the rear cover.
CAUTION : Data usage can only be used on one SIM Card.
2. Inserting aMicroSD memory card
It is possible to increase the internal memory of the CHIPO 3 with a MicroSD
card (32GB maximum).
•Turn off the phone and remove the back cover and battery.
• Insert the memory card into the slot provided.
• Then replace the battery and the back shell of the mobile phone.
CAUTION : Inserting or removing a SIM card and a MicroSD card requires the
complete shutdown of the mobile.
3. Installing and Charging battery
Battery Installation :
• Remove the back shell of your phone
• Insert the battery, making sure that the visual opposite is facing you
• Put back the back shell of the phone
CAUTION : Use only the battery supplied with your mobile phone. Model: Chipo3 Li-ion 3.7V /
800mAh. For any replacement concerning the battery, please contact the service department of
your reseller.
Battery charge :
• To charge the battery, plug the USB cable (supplied) into the USB port on your mobile phone
and connect the AC adapter to a power outlet.
• The battery charge icon illuminates during charging and indicates charging status.
• When the battery is fully charged, you can disconnect the device from the power outlet.
IMPORTANT :
• Mobile charging is only done via the charging station.
• Be sure to fully discharge your phone before charging it for the first time.
• The battery must be charged for at least 5 to 8 hours during the first charge.
26

English

Note : you can use the device while it is charging. It is possible that the full charge time of the
battery is longer.
Precautions to be taken for the charging of the battery :
• To charge the battery, use only the AC adapter that came with your device. Do not use any
other power supplies or electrical devices.
• The electrical outlet to which the appliance is connected must be installed near the
equipment and must always be easily accessible.
•Always wait at least 5 seconds after turning off the device before restarting it. Switching the
device off and on again immediately may damage the electrical circuits.
• Do not disassemble the battery. Do not throw the battery into fire or water. Do not charge
the battery if the ambient temperature exceeds 45°C.
• For repair or replacement of the battery, contact a qualified technician.
IMPORTANT :
• Battery life depends largely on how you use it. Do not expose the battery to temperatures
below 0°C or above 60°C. Its operation could be altered.
• Significant electromagnetic interference or electrostatic discharge can cause malfunction or
loss of data. If the unit does not work properly, reset the phone or unplug the AC adapter from
the electrical outlet, and then reconnect it.
4. Turn on/off your phone
• To switch on the phone, press and hold the On/Off button on the
mobile keypad for 3 seconds..
• If the phone is on, briefly press the Power button to put it into standby mode.
• To turn off the phone, press and hold the On/Off button for 3 seconds.
5. Lock/UnlockSIMcards
Your CHIPO 3 is a dual SIM mobile, it allows you to call with two subscriptions
on the same device. There are two slots for two SIM cards.
• When you start your mobile, it will prompt you to enter the PIN code of your two SIM cards
successively. (SIM1 then SIM 2).
• The emergency call feature allows you to call an emergency number without having to enter
the PIN code.
6. Lock/Unlock Keyboard
To unlock the keyboard :
• Press the Unlock button at the top left and press the * touch (star).
To lock your keyboard :
• Press the button at the top left and then press the * touch (star).
You can set the screen lock by adding a password.
CAUTION : Forgotten or lost password or PIN code permanently blocks
your mobile phone.In case of forgetting or loss, the product warranty will
not take effect for such negligence. Indeed, even a reset cannot solve this
problem. As a precaution, write down your password.
PASSWORD : _________________
Lock / Unlock
Buttons
27
