Universal Electronics 20-0048 - Telecom Behnke 20 Serie Instructions

Manual Door intercom devices a / b Series 20 / 30 / 50
GB GB
Connection
Please note: Additional configurations step can be found starting on page 52.

Universal electronics 20-0048

Additional
power supply
T
Lorries
Speaker to LS+ / - on additional power supply
to cf. universal electronics
20-0006 / 20-0018 / 20-0026 on page 14
Please note: Please adhere to the maximum
cable lengths indicated on page 39!
*Suitable installation material to adapt speaker, microphone and buttons at the door: Tapping box 20-9208 or patch cable 20-9308
as an alternative
51
T
Configuration of telephone numbers
Yellow: Configurations step 22
Blue: Configurations step 23
*
T
