Time setting must be done on the digital remote control, it is independent from the time setting of the wire feeder.
Saving and loading JOB on the SD card cannot be performed with the remote control. For such operations, use the wire feeder's
interface.
WELDING CYCLES
Standard 2T process :
Dstart
When pressing the trigger, the pre gas starts. When the wire comes into contact with the weld piece, a pulse starts the arc, then the welding cycle
starts. When releasing trigger, the wire feeding stops and a pulse clean cuts the wire before post gas. As long as post gas is active, pressing the trigger
quickly resumes the weld (stitch welding). Wait for the end of post gas to change the settings.
RC-HD1
Protected (locked) mode settings :
This section is used to adjust the limits of voltage and speed that will apply in the locked mode.
Time and date settings :
This section is used to set the date and time on the machine (useful when saving parameters).
Job mode :
: Replace the current program.
: Create a new save.
: Load a saved slot.
: Delete the current program.
: Can transfer programs from the machine to the SD card.
: Can transfer programs from the SD card to to the machine.
Gas post-Flow
T burn-back
