Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely hope that you are
completely satisfied with the contents of your kit. However, we would ask you to check all the parts before you start construction,
referring to the Parts List, as we cannot exchange components which you have already modified. If you find any part is not
acceptable for any reason, we will readily correct or exchange it once we have examined the faulty component. Just send the
offending part to our Model Department. Please be sure to include the purchase receipt and the enclosed complaint form, duly
completed.
We are constantly working on improving our models, and for this reason we must reserve the right to change the kit contents in
terms of shape or dimensions of parts, technology, materials and fittings, without prior notification. Please understand that we
cannot entertain claims against us if the kit contents do not agree in every respect with the instructions and the illustrations.
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings in the usual sense of the term. Building and
operating them safely requires a certain level of technical competence and manual skill, together with discipline and a
responsible attitude at the flying field. Errors and carelessness in building and flying the model can result in serious personal
injury and damage to property. Since we, as manufacturers, have no control over the construction, maintenance and operation
of our products, we are obliged to take this opportunity to point out these hazards and to emphasise your personal responsibility.
Additional items required for the "Merlin":
MULTIPLEX receiving system components for the Merlin
RX-6-SYNTH IPD receiver
alternatively:
or RX-7-DR light M-Link receiver
Nano S servo
Battery charger:
MULTIcharger LN-3008 EQU
for LiPo, LiIo and LiFe batteries (2S / 3S) and NiMH
and NiCd batteries (four to eight cells)
Merlin Tuning power set:
Contents:
Himax 2212-1180 motor, BL-20 S-BEC speed controller, 7 x 4" and 8 x 5" folding
propellers, taper collet, driver and 33 mm Ø spinner
Merlin Tuning power set, Li-Batt powered:
Contents:
As above, plus 1 x Li-Batt BX 3/1-450 (M6)
Flight battery: Li-Batt BX 3/1-450 (M6)
Receiver battery for glider version
Tools:
Pliers, side-cutters, screwdriver, scissors, balsa knife.
Note: please remove the illustration pages from the centre of the instructions.
Specification:
Wingspan:
Overall length:
All-up weight, glider, min. approx.:
All-up weight, electric, min. approx.:
Total surface area:
Wing loading, min.:
RC functions:
GB
35 MHz A+B band
40 / 41 MHz band
2.4 GHz
4 x required (2 x ailerons, elevator, rudder)
4 AAA / Micro cells, W-format
783 mm
598 mm
265 g
325 g
11.3 dm²
23 g/dm² glider, 29 g/dm² electric
Aileron, elevator, rudder, motor
# 21 4237
Order No. 5 5876
Order No. 5 5877
Order No. 5 5810
Order No. 6 5120
Order No. 9 2540
Order No. 33 2653
Order No. 33 3653
Order No. 15 7104
Not in MPX range
