PANNEAU DE COMMANDE

1
11
1
Led bi-couleur de signalisation état chaudière
2
Led fonctionnement/sélection sanitaire
3
Manomètre
4
Led fonctionnement/sélection chauffage
5
Touche déblocage
6
Ecran à 4 chiffres
7
Touche chauffage/mémorisation paramètres
8
Touche diminution
9
Touche augmentation
10
Touche sanitaire/sélection paramètres
11
Touche sélection champ de fonctionnement
2
10
BEDIENINGSPANEEL
3
+
-
9
8
1
LED (tweekleuring): aanduiding werkingsstaat ketel
2
LED aanduiding functionaliteit sanitair
3
Manometer
4
LED aanduiding functionaliteit verwarming
5
Resettoets
6
Uitlezing met 4 karakters
7
Toest verwarming / opslag (vastleggen) parameters
8
Verminderingstoets
9
Vermeerderingstoets
10
Toets sanitair / selectie parameters
11
Toets selectie werkingsveld
4
5
6
7
17
