Sequencer control switch settings
You can use the UA-700's sequencer control switch to start/stop playback or recording on your
sequencer.
Settings for SONAR 1.0
1. From the Options menu, choose MIDI Devices.
In the MIDI Devices dialog box, select [EDIROL UA-700 CONTROL] as both the Inputs and Outputs.
2. From the Options menu, choose Key Bindings.
Make the following settings in the Key Bindings dialog box.
fig.sonar
[Type of Keys]
Check "MIDI" and "Enable"
[MIDI 'Shift' Options]
Check "Key", and input "C 0"
N Stopping the sequencer
3. In the [Bindings] area, set [Key] to [D 0].
4. In the [Function] area, select [Transport | Stop].
5. Click the [Bind] button.
The [Key] [D 0] will be connected to the [Function] area [Transport | Stop].
If you also want to assign the UA-700's PLAY button (Sequencer Control switch) to start recording on
your sequencer, proceed to step 6. If you want to assign the PLAY button (Sequencer Control switch) to
start playback on your sequencer, proceed to step 10. If you have now finished making settings, click the
[OK] button. The Shortcut Key dialog box will close, and the settings will be completed.
N Starting recording
6. In the [Bindings] area, set [Key] to [D 0].
7. In the [Function] area, select [Transport | Record].
8. Click the [Bind] button.
The [Key] [D 0] will be connected to the [Function] area [Transport | Record].
9. Click [OK] to close the Key Bindings dialog box and complete the setting.
N Starting playback
10. In the [Bindings] area, set [Key] to [E 0].
11. In the [Function] area, select [Transport | Play].
12. Click the [Bind] button.
The [Key] [E 0] will be connected to the [Function] area [Transport | Play].
13. Click [OK] to close the Key Bindings dialog box and complete the setting.
Advanced applications
143
