Features of the UA-700
Thank you, and congratulations on your choice of the UA-700. The UA-700 is an audio interface
that can be connected to your computer via a USB cable, allowing you to digitally record and play
back high-quality audio data.
Built-in COSM effects
The UA-700 features the same COSM engine that has won acclaim with the BOSS GP-20 and GT-6.
From the heavy distortion of a tube amp, to a lightly distorted crunch sound, or the clean sound
typical of a JC-120, these effects deliver the powerful tones of a guitar amp, faithfully simulating
even the subtle impact of picking and volume.
24-bit/96 kHz data for pristine audio quality
You can enjoy high-quality digital recording/playback on your computer using 24-bit/96 kHz*
data.
* Your application must support 24-bit/96 kHz data.
* Simultaneous recording and playback at 96 kHz is not possible.
Wide variety of input/output jacks
Two combo-type jacks, which provide both XLR balanced (with phantom power) and TRS
balanced inputs, are provided. One input provides a high-impedance (Hi-Z) connection for
directly connecting your guitar or bass. The UA-700 also provides RCA phono-type inputs and
outputs, phone outputs, and digital input/output jacks (coaxial and optical), making it possible for
you to readily connect almost any kind of device.
Direct Monitor function
The Direct Monitor function lets you monitor the input signal directly from headphones or the
analog outputs without passing the audio through your computer application. You can also switch
the monitor function on/off from an ASIO™ 2.0 compatible application.
WDM/ASIO 2.0 drivers included
You can enjoy high performance with WDM compatible applications such as SONAR™, and ASIO
compatible applications such as Cubase™ and Logic™. Of course you can also use applications
that support MME (Windows®) or Sound Manager (Mac OS®).
* Roland provides no guarantee or support regarding the operation of sequencer software or audio
editing software made by other companies. Please contact the manufacturer of the software you are
using.
10
